- Easy Entry frame for effortless mounting
- Bosch Active Plus motor for smooth rides
- Shimano Deore 10-speed drivetrain for versatility
- Hydraulic disc brakes for reliable stopping power
- Integrated lights and mudguards for urban use
| Accessories: | KICKSTAND: Cubestand Cmpt / BELL: Cube Classic / CARRIER: Cube Integrated Carrier 2.0, Cube Adapter Compatible, SnapIt Compatible |
|---|---|
| Battery: | Bosch PowerPack 400 / CHARGER: Bosch 2A |
| Brakes: | Shimano BR-MT400, Hydr. Disc Brake (180/180) |
| Chain: | KMC X10 |
| Crankset: | ACID E-Crank, 38T, 165mm |
| Derailleur rear: | Shimano Deore RD-M5120-SGS, 10-Speed |
| Display: | Bosch Purion |
| Fender: | SKS Chrom Shiny |
| Fork: | SR Suntour NEX-E25, 50mm |
| Frame: | Aluminium Superlite, Comfort Ride Geometry, Premium Comfort And Safety, Integrated Carrier 2.0 |
| Freewheel: | Shimano Deore CS-M4100, 11-46T |
| Grip: | Cube Retro |
| Handlebar: | Cube Comfort Shape Bar |
| Handlebar stem: | Cube Comfort City Stem, 31.8mm |
| Headset: | Cube FPH835D, Semi-Integrated |
| Hubs: | FRONT: Shimano HB-M4050, QR, Centerlock / REAR: Shimano FH-M4050, QR, Centerlock |
| Light(s): | FRONT: Trelock Bike-i Retro Ebike, 12V, DC / REAR: Herrmans H-Trace |
| Lights: | FRONT: Trelock Bike-i Retro Ebike, 12V, DC / REAR: Herrmans H-Trace |
| Motor drive unit: | Bosch Drive Unit Active Plus Generation 3 (50Nm) Cruise (250Watt) |
| Pedals: | ACID PP Trekking |
| Rim: | Cube SX24, Disc, 36H |
| Saddle: | Cube Retro |
| Season: | 2021 |
| Seat clamp: | Cube Screwlock, 31.8mm |
| Seat post: | Cube Performance Post, 27.2mm |
| Shifters: | Shimano Deore SL-M4100, Rapidfire Plus |
| Tyre front: | Schwalbe Little Big Ben, Active, 40-622 |
| Tyre rear: | Schwalbe Little Big Ben, Active, 40-622 |
| Weight: | 24.4kg |
| Wheel size: | 700c |
| Frame size | XS (45cm) | S (49cm) | M (53cm) | L (57cm) |
|---|---|---|---|---|
| Seat tube | 450 | 490 | 530 | 570 |
| Top Tube Horizontal | 578 | 593 | 608 | 623 |
| Seat Angle | 73 | 73 | 73 | 73 |
| Head Tube Angle | 70 | 70 | 70 | 70 |
| Chainstays | 455 | 455 | 455 | 455 |
| Head Tube (length) | 170 | 185 | 200 | 220 |
| Wheelbase | 1082 | 1098 | 1114 | 1130 |
| BB Height to Hub axle | -75 | -75 | -75 | -75 |
| Standover Height (50mm from BB) | 513 | 511 | 511 | 511 |
| Standover Height (80mm from BB) | 509 | 507 | 508 | 509 |
| Reach | 376 | 390 | 401 | 410 |
| Stack | 651 | 662 | 680 | 697 |
| Wheel Size | 28 | 28 | 28 | 28 |
Cube Ella Hybrid Bike Sizing Chart
