- Bosch Drive Unit Performance Line Cruise Gen3
- Integrated Bosch PowerTube 500 Battery
- Easy entry Trapeze Frame Design
- SR Suntour 100mm Front Fork
- Shimano Alivio / Tourney 1x9 Speed Drivetrain
- Shimano MT200 Hydraulic Disc Brakes
- Size split, S: 27.5” wheels, M & L: 29” wheels
| Accessories: | KICKSTAND; CUBEstand Cmpt / Easy Bell |
|---|---|
| Battery: | Bosch PowerTube 500, Charger: Bosch 2A |
| Brakes: | Tektro HD-M275 Disc brakes |
| Chain: | KMC X9 |
| Colour: | metallicgrey´n´white |
| Crankset: | ACID E-Crank, 175mm, 38T |
| Derailleur rear: | Shimano RD-M3100-SGS, 9-Speed |
| Display: | Bosch Purion |
| Fender: | ACID 65 BB-Mount |
| Fork: | SR Suntour NVX30 Coil, 100mm |
| Frame: | Aluminium Superlite, Gravity Casting, Agile Ride Geometry, Tapered Headtube, Internal Cable Routing, Full Integrated Battery, Kickstand/Fender/Carrier Mounting Points |
| Freewheel: | Shimano CS-HG201, 11-36T Cassette |
| Grip: | CUBE Race Grip 31mm, 1-Clamp |
| Handlebar: | CUBE Rise Trail Bar, 720mm |
| Handlebar stem: | CUBE Performance Stem Pro, 31.8mm |
| Headset: | 27.5: ACROS AZX-1041, BlockLock 135°, 1 1/8" straight, Top Zero-Stack 1 1/8" (ZS 44mm), Bottom Zero-Stack 1 1/2" (ZS 56mm) // 29: ACROS AZF-1039, 1 1/8" straight, Top Zero-Stack 1 1/8" (ZS 44mm), Bottom Zero-Stack 1 1/2" (ZS 56mm) |
| Hubs: | FRONT: Shimano HB-TX505, QR, Centerlock / REAR: Shimano FH-TX505, QR, Centerlock |
| Light(s): | FRONT: CUBE Shiny 50 Lux, 12V, DC / REAR: ACID Mudguard Rear Light PRO-E, 12V, DC |
| Lights: | FRONT: CUBE Shiny 50 Lux, 12V, DC / REAR: ACID Mudguard Rear Light PRO-E, 12V, DC |
| Motor drive unit: | Bosch Drive Unit Performance Line Cruise 20pmh Gen3 US (2020) |
| Pedals: | CUBE PP MTB |
| Rim: | CUBE EX23, 32H, Disc, Tubeless Ready |
| Saddle: | Natural Fit Sequence |
| Season: | 2022 |
| Seat clamp: | CUBE Varioclose, 34.9mm |
| Seat post: | CUBE Performance Post, 30.9mm |
| Shifters: | Shimano SL-M3100-R, Rapidfire-Plus |
| Tyre front: | Schwalbe Smart Sam, Active, 2.35 |
| Tyre rear: | Schwalbe Smart Sam, Active, 2.35 |
| Wheel size: | 29" / 27.5" (Varies by Frame Size) |
SIZE | Trapeze 15" / 27.5 / S | Trapeze 17" / 29 / M | Trapeze 19" / 29 / L |
SEAT TUBE | 355 | 405 | 450 |
TOP TUBE HORIZONTAL | 560 | 580 | 600 |
SEAT TUBE ANGLE | 74 | 74 | 74 |
HEAD TUBE ANGLE | 68 | 68 | 69 |
CHAIN STAYS | 472 | 488 | 488 |
HEAD TUBE | 120 | 115 | 120 |
WHEELSBASE | 1128 | 1167 | 1176 |
BB-HEIGHT TO HUB | 48 | 65 | 65 |
STANDOVER HEIGHT | 682 | 699 | 707 |
REACH | 389 | 401 | 418 |
STACK | 602 | 628 | 638 |
Cube Reaction Hybrid Bike Sizing Chart
