Marin Headlands 1 Gravel Bike Charcoal/Black/Orange

Marin Headlands 1 Gravel Bike Charcoal/Black/Orange

Brand: Marin

SKU: Select a size

Size: Select a size

SM MD LG XL

Not sure what sized bike is best?

Answer a few short questions and we'll make a recommendation on which size is best for you.

REQUEST A PRICE BEAT

Pick up Delivery

Your store:

No location set

No click & collect information available for this location.

Click & Collect:

In Store

Select a size to view stock availability at this store.

$9.90 Not available

Select a size to view stock availability at this location.

Carbon Frame/ Marin Carbon Fork

Rigid Front Travel

700c Wheel Size

Hydraulic Disc Brake

Shimano GRX Groupset

1 x 11 Speed

Have a Question? Ask an expert on 0800 000 283

Product Details

Description

Named after one of the most iconic sections of coastline and Insta-inspiring gravel riding of the American West, the new Marin Headlands embodies everything about this beautiful and rugged terrain. A full unidirectional carbon chassis is purpose-built for multi-surface adventures. The 1x specific construction of the frame means short chainstays that still fit up to 700x45mm tires, and paired with the longer top tube and shorter stems the bike takes cues from modern mountain bikes on technical off-road trail, while still maintaining a comfortable, fast, and efficient ride on flatter terrain. Internal cable routing and tons of mounts on the frame allow you to fit the bike with anything from water bottles and tubes, to various frame bags using the attachments found around the front triangle, conventional rack and fender mounts also transition the Headlands into a capable winter commuter.

Key Features

Full unidirectional carbon chassis
1x specific frame construction
Fits up to 700x45mm tyres
Internal cable routing for clean aesthetics
Multiple mounts for accessories and racks

Specifications

Product Overview

Product

Marin Headlands 1 Gravel Bike Charcoal/Black/Orange

Brand

Marin

Parent SKU

G2UQHWK2

Size SKUs

SM: MAAD2132431002
MD: MAAD2132431003
LG: MAAD2132431004
XL: MAAD2132431005

Matrix Barcodes

SM: 843346108531
MD: 843346108548
LG: 843346108555
XL: 843346108562

Year Model

2022

Product Features

Frame Material

Carbon

Colour

Black

Wheel Size

700c

Brake Type

Hydraulic Disc Brake

Gears

1 x 11

Fork Material

Carbon

Build

Frame

Unidirectional Carbon Beyond Road Platform, 1x Drivetrain Specific, 700c x 45mm/650B x 50mm Compatible, Flat Mount Disc, 142x12mm Thru-Axle, Internal Dropper Post Routing, Internal Housing Routing, Mudguard and Rear Carrier Mounting, Plentiful Gear Mounts

Fork

Marin Full Carbon w/ Tapered Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets

Handlebars

Marin Butted Alloy, Compact 12º Flared Drop, Flat Top

Headset

FSA Orbit IS, Sealed Cartridge Bearings, 1 1/8” x 1 1/2”

Grips

Marin Shock Absorbing Tape

Stem

Marin 3D Forged Alloy

Bottom Bracket

External Sealed Cartridge Bearings

Pedals

Commute Platform

Saddle

Marin Beyond Road Concept

Seat Post

Marin Alloy, 27.2mm

Wheels

Wheel Size

700c

Rims

Marin Aluminum Double Wall, 21mm Inner, 21mm Tall, Disc Specific, Tubeless Compatible

Hubs

REAR: Forged Aluminum Alloy, XD Driver, 6-Bolt Disc, 32H / FRONT: Forged Aluminum Alloy, 6-Bolt Disc, 32H

Tyres

Schwalbe G-One Performance, 700Cx40mm, Folding Bead

Spokes

14g Black Stainless Steel

Groupset

Crankset

Forged Alloy 1x11, Hollow CrMo Spindle, Narrow Wide 40T

Chain

KMC X11

Brakes

Shimano GRX Hydraulic Disc, 160mm Rotor

Shifters

Shimano GRX RX600

Rear Derailleur

Shimano GRX Shadow w/ Clutch

Cassette

11 Speed

Find Your Size

Step 1: Measure your height

Take off your shoes
Stand with your back straight against a wall
Balance a book on your head to mark your height on the wall
Measure your height by the distance from the floor to the mark

Your height:

Find Your Size

Step 2: Adjust your inseam

Based on your height, we’ve calculated a starting point.
You can measure your inseam by tucking a book between your legs so there is pressure but it isn’t uncomfortable.
Inseam typically falls with 5cm of the average.

Your inseam:

Find Your Size

Your results

For the Marin Headlands 1 Gravel Bike Charcoal/Black/Orange we suggest the following size.

More comfort More speed

Height: --

Inseam: --

Adjusted Height: --

Find Your Size

We have saved your measurements.

Recommended sizes will now be highlighted on the page.

PERFECT RIDE GUARANTEE

If you don't love it, you can swap it, up to 30 days from purchase!* Learn more »

FREE BIKE BUILD

We'll build your bike for free when you click and collect at any 99 Bikes store.

FIRST FREE TUNE-UP

Every bike comes with a complimentary free tune-up and safety check. Learn more »

Not sure what sized bike is best?

Answer a few short questions and we'll make a recommendation on which size is best for you.

Your selected size: -

Legend

Available size

Current size

Unavailable size

Suggested sizing

Wheel Size

700c

Stack

Reach

Top Tube Length

Seat Tube Length

Seat Tube Angle

Fork Length

Head Tube Length

Head Tube Angle

Handlebar Height

Bottom Bracket Drop

Chainstay Length

Wheelbase

Standover Height

Minimum Seat Height

Maximum Seat Height
