$751 Off Full Price

Merida Scultura Team Road Bike Teal/Pearl

Merida Scultura Team Road Bike Teal/Pearl

Brand: Merida

SKU: Select a size

Size: Select a size

XS SM MD LG XL

Not sure what sized bike is best?

Answer a few short questions and we'll make a recommendation on which size is best for you.

REQUEST A PRICE BEAT

Pick up Delivery

Your store:

No location set

No click & collect information available for this location.

Click & Collect:

In Store

Select a size to view stock availability at this store.

$9.90 Not available

Select a size to view stock availability at this location.

Carbon Frame/ Merida Carbon Fork

Rigid Front Travel

700c Wheel Size

Hydraulic Disc Brake

Shimano Dura-Ace Di2 Groupset

2 x 12 Speed

Have a Question? Ask an expert on 0800 000 283

Product Details

Description

The Merida Scultura Team is crafted for competitive cyclists, combining cutting-edge technology with a lightweight design for optimal performance on the road. This bike is engineered with precision to meet the demands of serious riders, featuring a Scultura CF5 V MAT carbon frame and an aerodynamic design that enhances speed and efficiency. With its advanced Shimano Dura Ace Di2 groupset and stylish teal and pearl finish, the Scultura Team not only looks impressive but delivers a smooth, reliable ride. Ideal for both climbing and sprinting, this bike ensures you can push your limits and achieve peak performance on every ride.

Key Features

Scultura CF5 V MAT carbon frame for reduced weight and increased stiffness
Shimano Dura Ace Di2 groupset for precise electronic shifting
Aerodynamic design for enhanced performance
Versatile tire clearance with disc brakes for reliable stopping power
Striking teal and pearl finish for a standout look

Specifications

Product Overview

Product

Merida Scultura Team Road Bike Teal/Pearl

Brand

Merida

Parent SKU

U18GB4NS

Size SKUs

XS: MERR2502906
SM: MERR2502907
MD: MERR2502908
LG: MERR2502909
XL: MERR2502910

Year Model

2025

Product Features

Frame Material

Carbon

Colour

White

Wheel Size

700c

Brake Type

Hydraulic Disc Brake

Gears

2 x 12

Fork Material

Carbon

Build

Frame

SCULTURA CF5 V; MAT carbon; 700x30C max. WHS; 100x12/ 142x12 AST; Pressfit 86,5

Fork

SCULTURA CF5 disc; MAT carbon; 700x30C max. WHS

Handlebars

TEAM SL 1P INTEGRATED; MAT carbon; 380mm (3S-XXS-XS-S), 400mm (M-L-XL)

Headset

MERIDA TEAM SL (OP-203 neck)

Grips

Prologo One-Touch

Stem

TEAM ONE-PIECE INTEGRATED; MAT carbon 90mm-3S/XXS/XS, 100 mm-S, 110 mm-M/L, 120 mm-XL

Bottom Bracket

SM-BB92-41B, Pressfit 86.5

Saddle

SCRATCH M5; V-mount adapter; incl. MERIDA minitool

Seat Post

MERIDA TEAM SL; 27.2 DSP; 15 SSB; Carbon; S-Flex

Seat Clamp

MERIDA EXPERT

Wheels

Wheel Size

700c

Rims

METRON 45 SL Clincher TL Disc; 100x12 WHF; 142x12 WHR; 18 IWR; 45 HRI; Centerlock; MAT carbon; Tubeless ready (tubeless tape and valves included)

Groupset

Crankset

Shimano Dura Ace; 52-36 ATC; Power Meter 165 mm-3S/XXS, 170 mm-XS, 172.5 mm-S/M/L, 175 mm-XL

Chain

Shimano CN-M9100-12

Brakes

Shimano Dura Ace; Hydraulic disc

Front Rotor

Shimano CL900; 160mm

Rear Rotor

Shimano CL900; 160mm

Shifters

Shimano Dura Ace disc Di2

Rear Derailleur

Shimano Dura Ace Di2

Cassette

12 Speed

Find Your Size

Step 1: Measure your height

Take off your shoes
Stand with your back straight against a wall
Balance a book on your head to mark your height on the wall
Measure your height by the distance from the floor to the mark

Your height:

Find Your Size

Step 2: Adjust your inseam

Based on your height, we’ve calculated a starting point.
You can measure your inseam by tucking a book between your legs so there is pressure but it isn’t uncomfortable.
Inseam typically falls with 5cm of the average.

Your inseam:

Find Your Size

Your results

For the Merida Scultura Team Road Bike Teal/Pearl we suggest the following size.

More comfort More speed

Height: --

Inseam: --

Adjusted Height: --

Find Your Size

We have saved your measurements.

Recommended sizes will now be highlighted on the page.

PERFECT RIDE GUARANTEE

If you don't love it, you can swap it, up to 30 days from purchase!* Learn more »

FREE BIKE BUILD

We'll build your bike for free when you click and collect at any 99 Bikes store.

FIRST FREE TUNE-UP

Every bike comes with a complimentary free tune-up and safety check. Learn more »

Not sure what sized bike is best?

Answer a few short questions and we'll make a recommendation on which size is best for you.

Your selected size: -

Legend

Available size

Current size

Unavailable size

Suggested sizing

Merida Scultura Team Road Bike Teal/Pearl geometry diagram

Legend

ST Seat Tube
STA Seat Tube Angle
R Reach
TT Top Tube
BD Bottom Bracket Drop
S Stack
CS Chain Stay Length
HT Head Tube
WB Wheel Base
HTA Head Tube Angle
FL Fork Length

Wheel Size

700c

Stack

529

542

557

571

593

Reach

383

390

395

400

409

Top Tube Length

535

545

560

575

590

Seat Tube Length

458

481

501

521

550

Seat Tube Angle

74.0

73.5

73.0

Fork Length

385

Head Tube Length

112

128

140

155

176

Head Tube Angle

112.0

128.0

140.0

155.0

176.0

Handlebar Height

Bottom Bracket Drop

Chainstay Length

Wheelbase

Standover Height

745

765

782

800

823

Minimum Seat Height

Maximum Seat Height
