Merida One-Twenty 300 Trail Bike Grey

Brand: Merida

SKU: Select a size

Size: Select a size

LG XL

REQUEST A PRICE BEAT

Pick up Delivery

Your store:

No location set

No click & collect information available for this location.

Click & Collect:

In Store

Select a size to view stock availability at this store.

$9.90 Not available

Select a size to view stock availability at this location.

Alloy Frame/ Suntour Fork

130mm Front Travel / 130mm Rear

29" Wheel Size

Hydraulic Disc Brake

Shimano Cues Groupset

1 x 11 Speed

Have a Question? Ask an expert on 0800 000 283

Product Details

Description

The Merida One-Twenty 300 combines exceptional value with a high-performance 130 mm travel aluminium frame, making it the ideal introduction to full-suspension mountain biking. The P-Flex suspension minimises maintenance while maximising fun and control, and the SR Suntour suspension provides 130mm travel front and back to smooth out the bumps. The Shimano CUES 1x10 drivetrain offers precise and durable shifting, while hydraulic disc brakes provide reliable stopping power. Plus, the dropper post adds extra control on challenging descents.

Key Features

Suntour XCR34 lockout fork with 130mm travel
SR Suntour Edge shock with 130mm travel
Shimano 1x10 drivetrain
Hydraulic disc brakes
Merida Expert dropper post

Specifications

Product Overview

Product

Merida One-Twenty 300 Trail Bike Grey

Brand

Merida

Parent SKU

V8ZY40UH

Size SKUs

LG: MEDA2500783
XL: MEDA2500784

Matrix Barcodes

LG: 2500783
XL: 2500784

Year Model

2025

Product Features

Frame Material

Alloy

Colour

Grey

Wheel Size

29"

Brake Type

Hydraulic Disc Brake

Gears

1 x 11

Front Travel

130mm

Rear Travel

130mm

Weight

15.3kg (MD)

Build

Frame

ONETWENTY LITE V 130 STR MAT aluminium 29x25 max WHS 148x12 AST BSA BBR

Fork

Suntour XCR34 2CR; Air; 130 STR; Tapered; lockout; 44mm fork offset; 29x2.4" max WHS

Shock

SR Suntour Edge Plus 2CR; lockout

Handlebars

MERIDA COMP TR; MAT aluminium; 780 WHB; 20 RHB

Grips

MERIDA COMP EC

Stem

MERIDA EXPERT TR; MAT aluminium; 35 DSH; 0 ASD

Bottom Bracket

Samox BSA 24mm EB2401

Saddle

MERIDA COMP SL; 25% recycled material; V-mount

Seat Post

MERIDA EXPERT TR II; 34.9 DSP; 0 SSB; XSHORT/SHORT: 150 SPT - MID: 170 SPT - LONG, XLONG: 200 SPT

Wheels

Wheel Size

29"

Rims

MERIDA COMP CC II; 25 IWR; MAT aluminium; tubeless ready

Tyres

Maxxis Rekon, 29x2.4", wire

Groupset

Crankset

170 mm for all sizes

Chain

KMC xGlide

Brakes

Shimano MT200

Front Rotor

Shimano RT10; 180mm

Rear Rotor

Shimano RT10; 180mm

Shifters

Shimano CUES U6000

Rear Derailleur

Shimano CUES U6000; GS

Cassette

11 Speed

Frequently Asked Questions

What is the Merida One‑Twenty 300 Trail Bike used for?

The Merida One‑Twenty 300 Trail Bike is used for trail and all-mountain riding, offering a balanced 130 mm of suspension to smooth rough singletrack, jumps, and technical descents while remaining efficient on climbs.

Why choose the Merida One‑Twenty 300 Trail Bike?

Choose the Merida One‑Twenty 300 Trail Bike for its great value—an aluminium 130 mm full-suspension frame, reliable Shimano CUES 1x10 drivetrain, hydraulic disc brakes, and low-maintenance P-Flex design that maximises fun and control.

Who is the Merida One‑Twenty 300 Trail Bike designed for?

The Merida One‑Twenty 300 Trail Bike is designed for riders stepping up into full-suspension trail bikes—those who want capable, confidence-inspiring handling and durable components without breaking the bank.

Find Your Size

Step 1: Measure your height

Take off your shoes
Stand with your back straight against a wall
Balance a book on your head to mark your height on the wall
Measure your height by the distance from the floor to the mark

Your height:

Find Your Size

Step 2: Adjust your inseam

Based on your height, we’ve calculated a starting point.
You can measure your inseam by tucking a book between your legs so there is pressure but it isn’t uncomfortable.
Inseam typically falls with 5cm of the average.

Your inseam:

Find Your Size

Your results

For the Merida One-Twenty 300 Trail Bike Grey we suggest the following size.

More comfort More speed

Height: --

Inseam: --

Adjusted Height: --

Find Your Size

We have saved your measurements.

Recommended sizes will now be highlighted on the page.

PERFECT RIDE GUARANTEE

If you don't love it, you can swap it, up to 30 days from purchase!* Learn more »

FREE BIKE BUILD

We'll build your bike for free when you click and collect at any 99 Bikes store.

FIRST FREE TUNE-UP

Every bike comes with a complimentary free tune-up and safety check. Learn more »

130 mm Front & Rear Travel

Smooth, confidence-building 130 mm SR Suntour suspension front and rear so you can tackle rough trails with control. Lockout options let you dial in efficiency on climbs and flats.

Reliable, Low-Maintenance Drivetrain

Shimano CUES 1x10 shifting and a KMC xGlide chain deliver crisp, durable gear changes with minimal fuss. The P-Flex suspension layout reduces service needs while keeping handling predictable.

Trail-Ready Stopping & Control

Hydraulic Shimano MT200 disc brakes with 180 mm rotors give consistent, powerful braking in all conditions. A Merida Expert dropper post and wide 780 mm handlebar add confidence on descents and technical sections.

Your selected size: -

Legend

Available size

Current size

Unavailable size

Suggested sizing

Merida One-Twenty 300 Trail Bike Grey geometry diagram

Legend

ST Seat Tube
STA Seat Tube Angle
R Reach
TT Top Tube
BD Bottom Bracket Drop
S Stack
CS Chain Stay Length
HT Head Tube
WB Wheel Base
HTA Head Tube Angle
FL Fork Length

Wheel Size

29"

Stack

618

622

Reach

485

505

Top Tube Length

611

632

Seat Tube Length

445

470

Seat Tube Angle

78.5

Fork Length

541

Head Tube Length

110

115

Head Tube Angle

110.0

115.0

Handlebar Height

Bottom Bracket Drop

Chainstay Length

Wheelbase

Standover Height

754

756

Minimum Seat Height

Maximum Seat Height
