Merida eOne-Eighty 700 Electric Enduro Bike 800Wh Battery Heritage Red/Brown

Merida eOne-Eighty 700 Electric Enduro Bike 800Wh Battery Heritage Red/Brown

Brand: Merida

SKU: Select a size

Size: Select a size

SM MD LG XL

Not sure what sized bike is best?

Answer a few short questions and we'll make a recommendation on which size is best for you.

REQUEST A PRICE BEAT

Pick up Delivery

Your store:

No location set

No click & collect information available for this location.

Click & Collect:

In Store

Select a size to view stock availability at this store.

$9.90 Not available

Select a size to view stock availability at this location.

Steep Hills & Heavy Loads / 85 Nm Torque

Up to 93 km Range

Bosch Performance CX Motor

Alloy Frame/ RockShox Alloy Fork

180mm Front Travel / 180mm Rear

800Wh Battery

Have a Question? Ask an expert on 0800 000 283

Product Details

Description

The Merida eOne-Eighty 700 Electric Enduro Bike is built for riders who crave the thrill of aggressive trails and technical descents. Equipped with a Bosch Performance Line CX motor and a powerful 800Wh battery, this electric enduro bike offers plenty of support for long, challenging rides. Its 180mm RockShox suspension and SRAM GX Eagle drivetrain ensure smooth handling and reliable performance over rough terrain, while the hydraulic disc brakes deliver excellent stopping power in all conditions.

Key Features

Aluminium frame with 180mm suspension travel
Bosch Performance Line CX motor, 32KPH assist
RockShox Zeb Select fork with 180mm travel
SRAM GX Eagle drivetrain for smooth shifting
Powerful Sram DB8 Stealth hydraulic brakes

Specifications

Product Overview

Product

Merida eOne-Eighty 700 Electric Enduro Bike 800Wh Battery Heritage Red/Brown

Brand

Merida

Parent SKU

4PS6EIWU

Size SKUs

SM: MEEB2503253
MD: MEEB2503254
LG: MEEB2503255
XL: MEEB2503256

Year Model

2025

Product Features

Frame Material

Alloy

Colour

Red

Wheel Size

29" / 27.5" (Mullet Bike)

Brake Type

Hydraulic Disc Brake

Gears

1 x 12

Fork Material

Alloy

Front Travel

180mm

Rear Travel

180mm

Motor and Battery System

Drive Type

Mid Drive

Motor Brand

Bosch

Motor

Bosch Performance Line CX / CR-038 PC bottom cover

Torque (Nm)

Motor Climbing Ability

Steep Hills & Heavy Loads

Battery Size (Watt-Hours)

800

Battery

Bosch PowerTube 800 ; 800Wh

Max. Range (KMs)

Display

Bosch Purion 400 / Bosch Mini Remote Switch

Build

Frame

eONE-EIGHTY LITE I; 160 STR; 29

Fork

Rockshox Zeb Select eMTB; Air; 180 STR; Tapered; 44mm fork offset; 29x2.6" max WHS

Shock

Rock Shox Vivid Select

Handlebars

MERIDA EXPERT eTR; 780 WHB; XS,S 20RHB ; M,L,XL 30RHB

Headset

Acros ICR MERIDA EXTERNAL neck w/ Blocklock

Grips

MERIDA EXPERT EC

Stem

MERIDA EXPERT eTR II; MAT aluminium; 35 DSH; 0 ASD; Supernova mount / 40 mm all sizes

Pedals

VP VP-532

Saddle

MERIDA COMP SL; V-mount; incl. MERIDA minitool

Seat Post

MERIDA TEAM TR II; 34.9 DSP; 0 SSB; all sizes 30-230 SPT

Seat Clamp

MERIDA EXPERT

Wheels

Wheel Size

29" / 27.5" (Mullet Bike)

Hubs

Shimano TC500; 15x100 WHF; 32 SPH; Centerlock / Shimano TC500; 12x148 WHR; 32 SPH; Centerlock

Spokes

Black stainless

Groupset

Crankset

Sram Eagle Transmission E-MTB for BOSCH; 36 ATC / Sram GX Eagle E-MTB Crank, 165mm all sizes

Chain

Sram NX Eagle

Brakes

Sram DB8 Stealth; 4 piston

Front Rotor

Sram HS2; 220mm

Rear Rotor

Sram HS2; 200mm

Shifters

Sram GX Eagle Single Click

Rear Derailleur

Sram GX Eagle

Cassette

12 Speed

Frequently Asked Questions

What is the Merida eOne‑Eighty 700 Electric Enduro Bike used for?

The Merida eOne‑Eighty 700 Electric Enduro Bike is used for aggressive enduro riding and technical mountain descents, providing strong motor support and long travel suspension for fast, challenging trail days.

Why choose the Merida eOne‑Eighty 700 Electric Enduro Bike?

Choose the Merida eOne‑Eighty 700 Electric Enduro Bike for its Bosch Performance Line CX motor with an 800Wh battery, 180mm suspension, and high-quality SRAM/RockShox components that combine to deliver power, range, and durable downhill performance.

Who is the Merida eOne‑Eighty 700 Electric Enduro Bike designed for?

The Merida eOne‑Eighty 700 Electric Enduro Bike is designed for experienced trail and enduro riders who want electric assist for longer, more aggressive rides and demand robust suspension and braking for technical terrain.

Disclaimer

Please Note: Before using this vehicle, check the applicable local laws relating to your intended use of the vehicle on roads and road related areas. Please ride responsibly and follow your local laws. We do not recommend modifying your electric bike or electric scooter.

Find Your Size

Step 1: Measure your height

Take off your shoes
Stand with your back straight against a wall
Balance a book on your head to mark your height on the wall
Measure your height by the distance from the floor to the mark

Your height:

Find Your Size

Step 2: Adjust your inseam

Based on your height, we’ve calculated a starting point.
You can measure your inseam by tucking a book between your legs so there is pressure but it isn’t uncomfortable.
Inseam typically falls with 5cm of the average.

Your inseam:

Find Your Size

Your results

For the Merida eOne-Eighty 700 Electric Enduro Bike 800Wh Battery Heritage Red/Brown we suggest the following size.

More comfort More speed

Height: --

Inseam: --

Adjusted Height: --

Find Your Size

We have saved your measurements.

Recommended sizes will now be highlighted on the page.

PERFECT RIDE GUARANTEE

If you don't love it, you can swap it, up to 30 days from purchase!* Learn more »

FREE BIKE BUILD

We'll build your bike for free when you click and collect at any 99 Bikes store.

FIRST FREE TUNE-UP

Every bike comes with a complimentary free tune-up and safety check. Learn more »

Range

Calculate your range

E-Bike Range Estimator

Free Test Rides

Come into your local store to test ride an E-Bike today

Find a store

Shop Our E-bikes

Shop our collection of electric bikes

Shop Now

Extreme trail capability

180mm front and rear travel with a stout alloy frame lets you attack steep, technical descents with confidence. Long-travel geometry keeps stability at speed and control on rough lines.

Powerful, long-range assist

Bosch Performance Line CX motor with an 800Wh PowerTube battery delivers strong 85 Nm support and extended ride time for all-day epics. Pedal-assist up to 25 kph keeps climbs fast and less fatiguing.

Race-level components

RockShox Zeb Select fork, RockShox Vivid Select shock, SRAM GX Eagle drivetrain and 4-piston Sram DB8 brakes offer reliable, precise control in demanding terrain. Mullet wheel option and eMTB-specific cranks mean performance where it counts.

Not sure what sized bike is best?

Answer a few short questions and we'll make a recommendation on which size is best for you.

Your selected size: -

Legend

Available size

Current size

Unavailable size

Suggested sizing

Merida eOne-Eighty 700 Electric Enduro Bike 800Wh Battery Heritage Red/Brown geometry diagram

Legend

ST Seat Tube
STA Seat Tube Angle
R Reach
TT Top Tube
BD Bottom Bracket Drop
S Stack
CS Chain Stay Length
HT Head Tube
WB Wheel Base
HTA Head Tube Angle
FL Fork Length

Wheel Size

29" / 27.5" (Mullet Bike)

Stack

657

661

666

670

Reach

435

460

485

505

Top Tube Length

577

604

630

652

Seat Tube Length

410

425

445

465

Seat Tube Angle

78.5

Fork Length

600

Head Tube Length

115

120

125

130

Head Tube Angle

115.0

120.0

125.0

130.0

Handlebar Height

Bottom Bracket Drop

Chainstay Length

Wheelbase

Standover Height

Minimum Seat Height

Maximum Seat Height
