$520 Off Full Price

Merida Big Nine TR 600 Cross-Country Mountain Bike Matt Red (Black)

Merida Big Nine TR 600 Cross-Country Mountain Bike Matt Red (Black)

Brand: Merida

SKU: Select a size

Size: Select a size

SM MD LG XL XXL

Not sure what sized bike is best?

Answer a few short questions and we'll make a recommendation on which size is best for you.

REQUEST A PRICE BEAT

Pick up Delivery

Your store:

No location set

No click & collect information available for this location.

Click & Collect:

In Store

Select a size to view stock availability at this store.

$9.90 Not available

Select a size to view stock availability at this location.

Alloy Frame/ Suntour Alloy Fork

120mm Front Travel

29" Wheel Size

Hydraulic Disc Brake

Shimano Mixed Groupset

1 x 11 Speed

Have a Question? Ask an expert on 0800 000 283

Product Details

Description

Progressive performance, without the big price. The Big Nine 600 TR uses Merida’s latest LITE aluminium frame to deliver cutting-edge geometry and handling that's also high on comfort and control thanks to a 120 mm SR Suntour fork, clearance for 2.4" tyres and their own dropper post. Whether you want to sprint singletrack or rip around race tracks, it's the perfect place to get started thanks to dependable Shimano 11-speed shifting and confident performance from hydraulic disc brakes.

Mountain biking is one of the most varied cycling disciplines and probably the most demanding when it comes to equipment. While full suspension bikes offer amazing riding characteristics, the classic hardtail remains one of the purest tools for the job. Merida’s 29er wheel equipped Big Nine range offers truly modern geometry with increased standover clearance and handling stability to better deal with the tough race tracks of today, with the downcountry ready TR option your can enjoy a boosted fork travel, aggressive tyres and dropper post. Merida’s hardtails are the backbone of their range and showcase the enormous wealth of experience and knowledge gained in almost half a century of bike production and manufacturing. The Big Nine range symbolizes the symbiosis between modern frame technology, attention to detail and craftsmanship.

Key Features

Lightweight aluminum frame for agility
High-performance suspension for smooth rides
29-inch wheels for enhanced stability
Shimano drivetrain for precise shifting
Disc brakes for reliable stopping power

Specifications

Product Overview

Product

Merida Big Nine TR 600 Cross-Country Mountain Bike Matt Red (Black)

Brand

Merida

Parent SKU

AE1C7A27

Size SKUs

SM: MEHA242402846
MD: MEHA242402847
LG: MEHA242402848
XL: MEHA242402849
XXL: MEHA242402850

Product Features

Frame Material

Alloy

Colour

Red

Wheel Size

29"

Brake Type

Hydraulic Disc Brake

Gears

1 x 11

Fork Material

Alloy

Front Travel

120mm

Weight

Max Weight: 135 kg Total weight of bike, rider and luggage

Build

Frame

BIG.NINE TR LITE III material: aluminium 29x2.4" max. wheelsize 148x12 mm axle standard BSA bottom bracket standard

Fork

SR Suntour Raidon 34 2CR Air 120 mm suspension travel Tapered platform 46 mm fork offset

Handlebars

MERIDA EXPERT CC material: aluminium 760 mm width flat

Headset

Acros ICR MERIDA EXTERNAL Upper and lower IPS sealing

Grips

MERIDA COMP EC

Stem

MERIDA TEAM CC III material: aluminium 31.8 mm diameter -6° stem angle S, M, L: 60 mm, XL, XXL 70 mm

Saddle

MERIDA COMP SL V-mount incl. MERIDA minitool

Seat Post

MERIDA COMP TR 30.9 mm diameter 0 mm setback S: 125 mm travel seatpost - M/L: 150 mm travel seatpost - XL/XXL 175 mm travel seatpost

Seat Clamp

MERIDA EXPERT

Wheels

Wheel Size

29"

Rims

MERIDA COMP CC II 25 mm inner width material: aluminium tubeless ready

Hubs

Shimano TC500-B / Shimano TC500-HM-B 110x15 mm width front hub 32 spoke holes Centerlock 148x12 mm width rear hub 32 spoke holes Centerlock

Spokes

Black stainless

Groupset

Crankset

MERIDA Expert TR 32 teeth 170 mm-S, 175 mm-M up

Chain

Shimano LG500

Brakes

Shimano MT200 2 piston

Front Rotor

Shimano RT10 180 mm

Rear Rotor

Shimano RT10 180 mm

Shifters

Shimano CUES U6000

Rear Derailleur

Shimano CUES U6000 GS

Cassette

11 Speed

Frequently Asked Questions

What is the Merida Big Nine TR 600 Mountain Bike used for?

The Merida Big Nine TR 600 Cross-Country Mountain Bike Matt Red (Black) is built for cross-country and downcountry riding — sprinting singletrack, ripping race tracks, and tackling varied trail terrain with a 120 mm fork and 29" wheels.

Why choose the Merida Big Nine TR 600 Mountain Bike?

Choose the Merida Big Nine TR 600 Cross-Country Mountain Bike Matt Red (Black) for its lightweight LITE aluminium frame, Shimano 11-speed drivetrain, and hydraulic disc brakes that deliver performance, control, and value.

Who is the Merida Big Nine TR 600 Mountain Bike designed for?

The Merida Big Nine TR 600 Cross-Country Mountain Bike Matt Red (Black) is aimed at riders who want a capable, hardtail race-ready bike — from ambitious beginners to experienced cyclists seeking a reliable, affordable trail machine.

Find Your Size

Step 1: Measure your height

Take off your shoes
Stand with your back straight against a wall
Balance a book on your head to mark your height on the wall
Measure your height by the distance from the floor to the mark

Your height:

Find Your Size

Step 2: Adjust your inseam

Based on your height, we’ve calculated a starting point.
You can measure your inseam by tucking a book between your legs so there is pressure but it isn’t uncomfortable.
Inseam typically falls with 5cm of the average.

Your inseam:

Find Your Size

Your results

For the Merida Big Nine TR 600 Cross-Country Mountain Bike Matt Red (Black) we suggest the following size.

More comfort More speed

XXL

Height: --

Inseam: --

Adjusted Height: --

Find Your Size

We have saved your measurements.

Recommended sizes will now be highlighted on the page.

PERFECT RIDE GUARANTEE

If you don't love it, you can swap it, up to 30 days from purchase!* Learn more »

FREE BIKE BUILD

We'll build your bike for free when you click and collect at any 99 Bikes store.

FIRST FREE TUNE-UP

Every bike comes with a complimentary free tune-up and safety check. Learn more »

Lightweight agility meets big-wheel stability

A LITE aluminium frame and 29" wheels deliver nimble handling with confident rollover on rough terrain. Designed for quick climbs and steady cornering on singletrack.

Smooth, downcountry-ready suspension

120 mm SR Suntour fork plus clearance for 2.4" tyres so you can push harder on rough trails. Includes dropper-post compatibility for aggressive descents and better control.

Dependable shifting and stopping

Shimano 11-speed drivetrain provides precise gear changes while hydraulic disc brakes give consistent stopping power. Built to perform reliably race after ride without breaking the bank.

XXL

Not sure what sized bike is best?

Answer a few short questions and we'll make a recommendation on which size is best for you.

Your selected size: -

Legend

Available size

Current size

Unavailable size

Suggested sizing

Merida Big Nine TR 600 Cross-Country Mountain Bike Matt Red (Black) geometry diagram

Legend

ST Seat Tube
STA Seat Tube Angle
R Reach
TT Top Tube
BD Bottom Bracket Drop
S Stack
CS Chain Stay Length
HT Head Tube
WB Wheel Base
HTA Head Tube Angle
FL Fork Length

Wheel Size

29"

Stack

614

624

633

643

Reach

420

440

460

480

500

Top Tube Length

594

614

637

659

681

Seat Tube Length

380

410

440

470

500

Seat Tube Angle

74.2

Fork Length

530

Head Tube Length

105

115

125

Head Tube Angle

95.0

105.0

115.0

125.0

Handlebar Height

Bottom Bracket Drop

Chainstay Length

Wheelbase

Standover Height

712

713

715

723

758

Minimum Seat Height

Maximum Seat Height
