$526 Off Full Price Clearance

Marin DSX FS Gravel Bike Gloss Blue/Tan

Brand: Marin

SKU: Select a size

Size: Select a size

MD LG XL

Not sure what sized bike is best?

Answer a few short questions and we'll make a recommendation on which size is best for you.

REQUEST A PRICE BEAT

Pick up Delivery

Your store:

No location set

No click & collect information available for this location.

Click & Collect:

In Store

Select a size to view stock availability at this store.

$9.90 Not available

Select a size to view stock availability at this location.

Alloy Frame/ Suntour Alloy Fork

under 100mm Front Travel

700c Wheel Size

Hydraulic Disc Brake

Shimano SLX Groupset

1 x 12 Speed

Have a Question? Ask an expert on 0800 000 283

Product Details

Description

The Marin DSX is everything you want from a modern, flat-bar gravel bike. Zippy aluminum frames, compliant forks, heaps of tire clearance, low standover, dropper post compatibility and a whole load of options for bags and fenders. Taking inspiration from the Gestalt X drop bar line, Marin made the DSX to feel like an MTB but still cut it on all of those adventures that would normally demand curly bars.

The Marin DSX FS model features a butted and formed Series 3 6061 aluminum frame with internal routing, 142x12mm thru-axles, flat mount disc brakes and rack and fender eyelets. Further breaking the gravel bikes mold, it’s decked out with a 60mm travel SR/Suntour GVX LOR front fork for hard-charging, off-road adventures. There’s also a 1 x 12 speed Shimano SLX/Deore drivetrain, fast rolling Vee Tire Co 44mm Rocket Man tires with room for 29x2.1” knobbies and Shimano hydraulic brakes with the latest flat mount disc brake standard for smooth, controlled stopping in all conditions with minimal maintenance. Rounding off the build is plenty of reliable Marin components and mounting points for bikepacking accessories. Is it a gravel bike? Is it a mountain bike? We’ve got no idea - we just know that it’s a whole mountain of fun.

Key Features

Lightweight aluminum frame for durability
Full suspension for enhanced comfort
Versatile tyre clearance for varied terrain
Disc brakes for reliable stopping power
Stylish gloss blue and tan finish

Specifications

Product Overview

Product

Marin DSX FS Gravel Bike Gloss Blue/Tan

Brand

Marin

Parent SKU

EKUNHOB0

Size SKUs

MD: MAHB249067002
LG: MAHB249067003
XL: MAHB249067004

Year Model

2024

Product Features

Frame Material

Alloy

Colour

Blue

Wheel Size

700c

Brake Type

Hydraulic Disc Brake

Gears

1 x 12

Fork Material

Alloy

Front Travel

under 100mm

Build

Frame

Series 3 DSX, Supension Adjusted Geometry, 6061 Aluminum, Tapered Head Tube, Relieved BB, Internal Cable Routing, Mudguard and Rack Mounts, Flat Mount Disc, 142x12mm Thru-Axle

Fork

SR/Suntour GVX LOR, 60mm Travel, Air Spring, Rebound Adjust, Lockout, Integrated Fender Mounts

Handlebars

Marin Mini Riser

Headset

FSA No.42 ACB, Sealed Cartridge Bearings, 1 1/8” x 1 1/2”

Grips

Marin MTB

Stem

Marin 3D Forged Alloy

Bottom Bracket

Sealed Outboard Bearing

Pedals

Nylon Platform

Saddle

Marin DSX

Seat Post

Marin Alloy

Wheels

Wheel Size

700c

Rims

Marin Aluminum Double Wall, 21mm Inner, Disc Specific, Tubeless Compatible

Hubs

FRONT: Forged Aluminum, 100x12mm, Disc, 32H / REAR: Forged Aluminum, 142x12mm, Disc Specific, 32H

Spokes

14g Black Stainless Steel

Groupset

Crankset

Forged Aluminum, 42T Steel Narrow Wide Chainring

Chain

KMC X12

Brakes

Tektro HDR285 Flat Mount Hydraulic

Front Rotor

160mm Rotor

Rear Rotor

160mm Rotor

Shifters

Shimano Deore, SLM6100, 12-Speed

Rear Derailleur

Shimano SLX, RD7100, 12-Speed

Cassette

12 Speed

Frequently Asked Questions

What is the Marin DSX FS Gravel Bike used for?

The Marin DSX FS Gravel Bike Gloss Blue/Tan is built for mixed-surface adventures—gravel rides, rough fire roads, and technical singletrack—while also handling commuter and bikepacking duties.

Why choose the Marin DSX FS Gravel Bike?

Choose the Marin DSX FS Gravel Bike Gloss Blue/Tan for its blend of a lightweight aluminum frame, 60mm front suspension, wide tyre clearance, hydraulic disc brakes, and practical rack/fender mounts that make it equally capable and comfortable off-road or loaded up.

Who is the Marin DSX FS Gravel Bike designed for?

The Marin DSX FS Gravel Bike Gloss Blue/Tan is aimed at riders who want mountain-bike confidence with flat-bar simplicity—adventure seekers, mixed-terrain commuters, and bikepackers who value comfort, versatility, and low maintenance.

Find Your Size

Step 1: Measure your height

Take off your shoes
Stand with your back straight against a wall
Balance a book on your head to mark your height on the wall
Measure your height by the distance from the floor to the mark

Your height:

Find Your Size

Step 2: Adjust your inseam

Based on your height, we’ve calculated a starting point.
You can measure your inseam by tucking a book between your legs so there is pressure but it isn’t uncomfortable.
Inseam typically falls with 5cm of the average.

Your inseam:

Find Your Size

Your results

For the Marin DSX FS Gravel Bike Gloss Blue/Tan we suggest the following size.

More comfort More speed

Height: --

Inseam: --

Adjusted Height: --

Find Your Size

We have saved your measurements.

Recommended sizes will now be highlighted on the page.

PERFECT RIDE GUARANTEE

If you don't love it, you can swap it, up to 30 days from purchase!* Learn more »

FREE BIKE BUILD

We'll build your bike for free when you click and collect at any 99 Bikes store.

FIRST FREE TUNE-UP

Every bike comes with a complimentary free tune-up and safety check. Learn more »

Lightweight, durable chassis

Built from Series 3 6061 aluminum with internal routing and thru-axles for a stiff, long-lasting ride. Low standover and smart geometry keep it nimble on mixed surfaces.

Smooth, confidence-inspiring suspension

A 60mm SR/Suntour GVX LOR fork and tuned frame compliance soak up rough trails and gravel. Enjoy better control and less fatigue on long, technical rides.

All-terrain versatility & load-ready

Room for 44mm fast-rolling rubber or 29x2.1” knobbies, plus rack and fender mounts for bikepacking. Hydraulic disc brakes and tubeless-ready rims give reliable stopping and lower maintenance.

Not sure what sized bike is best?

Answer a few short questions and we'll make a recommendation on which size is best for you.

Your selected size: -

Legend

Available size

Current size

Unavailable size

Suggested sizing

Marin DSX FS Gravel Bike Gloss Blue/Tan geometry diagram

Legend

ST Seat Tube
STA Seat Tube Angle
R Reach
TT Top Tube
BD Bottom Bracket Drop
S Stack
CS Chain Stay Length
HT Head Tube
WB Wheel Base
HTA Head Tube Angle
FL Fork Length

Wheel Size

700c

Stack

602

630

658

Reach

425

440

455

Top Tube Length

598

621

644

Seat Tube Length

480

520

558

Seat Tube Angle

74.0

Fork Length

Head Tube Length

120

150

180

Head Tube Angle

120.0

150.0

180.0

Handlebar Height

Bottom Bracket Drop

Chainstay Length

Wheelbase

Standover Height

708

738

761

Minimum Seat Height

Maximum Seat Height
