Marin Alcatraz 1 Dirt Jump Bike Blue Fade

Marin Alcatraz 1 Dirt Jump Bike Blue Fade

Brand: Marin

SKU: Select a size

Size: Select a size

SM LG

Not sure what sized bike is best?

Answer a few short questions and we'll make a recommendation on which size is best for you.

REQUEST A PRICE BEAT

Pick up Delivery

Your store:

No location set

No click & collect information available for this location.

Click & Collect:

In Store

Select a size to view stock availability at this store.

$9.90 Not available

Select a size to view stock availability at this location.

Alloy Frame/ Marin Chromoly Fork

26" Wheel Size

Mechanical Disc Brake

1 x 1 Speed

Have a Question? Ask an expert on 0800 000 283

Product Details

Description

The Alcatraz was designed from the ground up to be the best dirt jump and slopestyle bike you have ever ridden. Marin worked hand-in-hand with Matt Jones to define the exact needs of a modern dirt jump frame and are proud to release the complete Alcatraz into the world. At home boosting your local 6-pack, ripping up the pump track, or hitting the local skate park the Alcatraz has what you need to take care of business.

The Alcatraz 1 offers up a Series 3 aluminum frame built for the hard knocks, it’s stiff enough for lightning-fast acceleration and tough enough for the heavy hits. Short stays keep manuals easy and ambidextrous cable routing means you can run your brake on the left or right of the bars. There’s a suspension-corrected CrMo fork, front and rear Tektro mechanical disc brakes, Marin Custom Extrusion 26” Rims rolling on Vee Tire 2.25” rubber and plenty of bombproof Marin components. Best of all, it’s available in two frame sizes, regular and long to suit all rider heights.

Specifications

Product Overview

Product

Marin Alcatraz 1 Dirt Jump Bike Blue Fade

Brand

Marin

Parent SKU

UWQKTNGL

Size SKUs

SM: MAHA249116001
LG: MAHA249116002

Year Model

2024

Product Features

Frame Material

Alloy

Colour

Blue

Wheel Size

26"

Brake Type

Mechanical Disc Brake

Gears

1 x 1

Fork Material

Chromoly

Build

Frame

Series 3 6061 Aluminum, 26” Wheels, 135x10mm Horizontal Single Speed Dropouts, 73mm Threaded BB, ISCG 05 Tabs

Fork

Marin Series 2 CroMo 26", Suspension Corrected, 100x9mm Dropouts

Handlebars

Marin Riser, 6061 Double Butted Aluminum, 31.8mm at center bulge, 38mm Rise, 750mm Width, 4º Up, 9º Back

Headset

FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2”

Grips

Marin MTN, Closed End

Stem

Marin 3D Forged Alloy, 31.8mm clamp, 40mm extension

Bottom Bracket

External Sealed Cartridge Bearings

Pedals

Alloy Platform

Saddle

Marin DJ Saddle

Seat Post

Marin Alloy, 30.9mm

Accessories

Marin Chain Tension Device

Wheels

Wheel Size

26"

Rims

Marin Custom Extrusion, 27mm Inner, Pinned Joint

Hubs

FRONT: Forged Alloy, Bolt On 3/8" Axle, 100mm Spacing / REAR: Forged Alloy, 135x10mm, Bolt-On, Quad Sealed Bearings, Disc, 32H

Tyres

Vee Tire Co. XCV 26x2.25”, LSG Compound, Wire Bead

Spokes

14g Black Stainless Steel

Groupset

Crankset

Marin Forged Alloy, Alloy 32T Chainring, 104mm BCD

Chain

KMC HL-1

Brakes

Tektro MD-M280 Mechanical Disc

Front Rotor

160mm Rotor

Rear Rotor

160mm Rotor

Cassette

Single Speed

Frequently Asked Questions

What is the Marin Alcatraz 1 Dirt Jump Bike used for?

The Marin Alcatraz 1 Dirt Jump Bike is built for dirt jumping, slopestyle, pump track sessions, and skatepark riding—basically any high-energy, trick-oriented riding where pop and control matter.

Why choose the Marin Alcatraz 1 Dirt Jump Bike?

Choose the Marin Alcatraz 1 Dirt Jump Bike for its purpose-built Series 3 aluminum frame, suspension-corrected CroMo fork, and durable, ride-ready component set that keeps you shredding without constant upgrades. It’s engineered with input from pro riders to balance strength, stiffness, and playfulness.

Who is the Marin Alcatraz 1 Dirt Jump Bike designed for?

The Marin Alcatraz 1 Dirt Jump Bike is designed for riders who want a committed dirt-jump/slopestyle machine—from ambitious park riders and pump-track regulars to anyone looking to progress tricks with a tough, predictable bike.

Find Your Size

Step 1: Measure your height

Take off your shoes
Stand with your back straight against a wall
Balance a book on your head to mark your height on the wall
Measure your height by the distance from the floor to the mark

Your height:

Find Your Size

Step 2: Adjust your inseam

Based on your height, we’ve calculated a starting point.
You can measure your inseam by tucking a book between your legs so there is pressure but it isn’t uncomfortable.
Inseam typically falls with 5cm of the average.

Your inseam:

Find Your Size

Your results

For the Marin Alcatraz 1 Dirt Jump Bike Blue Fade we suggest the following size.

More comfort More speed

Height: --

Inseam: --

Adjusted Height: --

Find Your Size

We have saved your measurements.

Recommended sizes will now be highlighted on the page.

PERFECT RIDE GUARANTEE

If you don't love it, you can swap it, up to 30 days from purchase!* Learn more »

FREE BIKE BUILD

We'll build your bike for free when you click and collect at any 99 Bikes store.

FIRST FREE TUNE-UP

Every bike comes with a complimentary free tune-up and safety check. Learn more »

Bombproof, responsive chassis

Series 3 6061 aluminum frame and a suspension-corrected CroMo fork deliver stiff acceleration and durable construction for heavy landings. Built to take hard knocks while keeping you popping off jumps and bumps.

Trail-ready components out of the box

Tektro mechanical disc brakes, Marin custom 26" rims, and 2.25" Vee tires give reliable stopping power and traction right away. Everything is spec’d to minimize upgrades and maximize ride time.

Precision control and fit

Short chainstays, ambidextrous cable routing, and available regular and long frame sizes make manuals, whips, and park runs easier to dial in. Geometry and parts are tuned for quick handling and rider confidence.

Not sure what sized bike is best?

Answer a few short questions and we'll make a recommendation on which size is best for you.

Your selected size: -

Legend

Available size

Current size

Unavailable size

Suggested sizing

Marin Alcatraz 1 Dirt Jump Bike Blue Fade geometry diagram

Legend

ST Seat Tube
STA Seat Tube Angle
R Reach
TT Top Tube
BD Bottom Bracket Drop
S Stack
CS Chain Stay Length
HT Head Tube
WB Wheel Base
HTA Head Tube Angle
FL Fork Length

Wheel Size

26"

Stack

575

580

Reach

385

430

Top Tube Length

600

646

Seat Tube Length

320

Seat Tube Angle

69.0

Fork Length

Head Tube Length

115

120

Head Tube Angle

115.0

120.0

Handlebar Height

Bottom Bracket Drop

Chainstay Length

Wheelbase

Standover Height

370

400

Minimum Seat Height

Maximum Seat Height
