Marin San Quentin 3 Trail/Dirt Jump Bike White/Black

$2,479
?

You automatically get Club Price when buying online. But there are extra benefits if you join Club 99.

$3,199
Buy now, pay later
20% OFF FULL PRICE
SKU: MAHA2335955001 Low stock

5% Best Price Guarantee

If you find a cheaper price, we will beat it by 5%*

- Applies to any cheaper price found in New Zealand.

- When the competitor's final price inclusive of any taxes and delivery fees.

- Excludes Garmin products, other exclusions apply.

Perfect Ride Guarantee

If you don't love it, you can swap it, up to 30 days from purchase!* Learn more »

Free Bike Build

We'll build your bike for free when you click and collect at any 99 Bikes store.

First Free Tune-up

Every bike come with a complimentary free tune-up and safety check. Learn more »

Key Features
  • Series 3 6061 Aluminum, Double Butted Frame, Internal Cable Routing
  • Marzocchi Bomber Z2 140mm fork
  • Shimano Deore wide-range 12-speed drivetrain
  • Shimano MT420 4-piston brakes
  • Maxxis Assegai, 27.5x2.5" tubeless ready tyres
The San Quentin is for the aggressive hardtail trail rider looking for a blend between singletrack capabilities and extended air time. The slack head tube angle paired with a steep seat tube angle create a ride that will fly uphill with perfect front wheel precision but then descend like it’s on rails. The balanced rider position thanks to the steep seat tube puts your weight between the wheels for impressive climbing and handling on flats, while the slack front end and short rear center help to pull you through the rough descents and corners with an intuitive feel. The San Quentin 3 is the top dog in the SQ family. The Series 3 aluminium frame offers more advanced tube forming, more complex dropouts, post mount disc tabs, full internal cable routing, and a boost 148mm thru-axle. Fitted with a Marzocchi Bomber Z2 140mm fork, Shimano MT420 4-piston brakes and 12-speed Shimano deore drivetrain. As well as a X-Fusion dropper post, FSA cranks and rolling on Maxxis Assegai, 27.5x2.5” tyres.
Axles: Bolt-On Thru-Axle
Bottom bracket: Mego EXO 73mm BSA
Brakes: Shimano MT420, 4-Piston Hydraulic Disc, Metallic Pads
Chain: KMC X-12 Silver and Black
Crankset: FSA Comet, Modular 1x, 32T Direct Mount Chainring, MegaTooth Technology, Boost Spacing
Derailleur rear: Shimano Deore, 12-Speed, SGS
Fork: Marzocchi Bomber Z2, 110x15mm Boost Spacing, 140mm Travel, Kabolt Axle
Frame: All New Series 3 6061 Aluminum, Double Butted Frame, Internal Cable Routing, 12x148mm Thru-Axle, 73mm Threaded BB
Freewheel: Shimano, Deore 12-Speed cassette, 10-51T
Grip: Marin Grizzly, Lock On
Handlebar: Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back
Handlebar stem: Marin 3D Forged Alloy, 35mm
Headset: FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
Hubs: REAR: Shimano HB-MT410B, 148x12mm, Disc, Microspline Freehub Body / FRONT: Shimano HF-MT410B, 110x15mm, Disc
Pedals: Nylon Platform
Rim: Marin Aluminum Double Wall, Disc Specific, 29mm Inner, Sleeved Joint, 32H, Tubeless Compatible
Rotor front: 203mm Rotor
Rotor rear: 180mm Rotor
Saddle: Marin Speed Concept
Season: 2023
Seat post: X-Fusion Manic, 1x Composite Remote, Size S 150mm Travel, All Other Sizes: 170mm Travel, 30.9mm
Spokes: 14g Black Stainless Steel
Tyre front: Maxxis Assegai, 27.5x2.5", 3C MAXX TERRA, EXO, Tubeless Compatible
Tyre rear: Maxxis Assegai, 27.5x2.5", 3C MAXX TERRA, EXO, Tubeless Compatible
Wheel size: 27.5" (650b)

SMLXL
Stack618622.5631.5636
Reach422450470500
Headtube Angle64°64°64°64°
Headtube Length110115125130
Seattube Angle77°77°77°77°
Seattube Length310340375414
Toptube Effective564.7593.7615.8646.8
BB Height316316316316
BB Drop50505050
Chainstay425425425425
Wheelbase1173.41203.612281260.2
Standover Height627.7656.4664.8681
Fork Offset47474747
Seatpost Diameter30.930.930.930.9
Handlebar Width780780780780
Stem Length35353535
Crank Length170170170170

All lengths in millimeters

Marin San Quentin Bike Sizing Chart

Marin Bikes are Made For Fun. Since the first mountain bikes bearing the Marin name debuted in 1986, the brand has been dedicated to enriching the lives of riders by making fun, high caliber bicycles, which provide years of riding enjoyment. They operate their business based on hard work, fueled by passion, and fulfilled by the satisfaction of bringing the joy of cycling to riders across the world.
