Features
Marin Pine Mountain 1 Hardtail Mountain Bike Grey
5% Best Price Guarantee
If you find a cheaper price, we will beat it by 5%*
- Applies to any cheaper price found in New Zealand.
- When the competitor's final price inclusive of any taxes and delivery fees.
- Excludes Garmin products, other exclusions apply.
Perfect Ride Guarantee
If you don't love it, you can swap it, up to 30 days from purchase!* Learn more »
Free Bike Build
We'll build your bike for free when you click and collect at any 99 Bikes store.
First Free Tune-up
Every bike come with a complimentary free tune-up and safety check. Learn more »
- Series 2 Double Butted CrMo frame
- Multiple brazed-in cargo attachment points
- Exclusive Pine Mountain bedroll handlebar
- RockShox Recon RL, 120mm fork
- Shimano Deore 1 x 11-Speed groupset
- Shimano MT420 hydraulic disc brakes
- Vee Tire Flow Snap, 29 x 2.6" tyres
| Axles: | Bolt-On Thru-Axle |
|---|---|
| Bottom bracket: | External Sealed Cartridge Bearings |
| Brakes: | FRONT: Shimano MT420, 4-Piston, Hydraulic Disc, 180mm Rotor / REAR: Shimano MT400, 2-Piston, Hydraulic Disc, 160mm Rotor |
| Brake levers: | Shimano MT400 Hydraulic |
| Brake type: | Hydraulic Disc Brake |
| Cassette: | 11 Speed |
| Chain: | KMC X11 |
| Chainset: | Single |
| Crankset: | Marin Forged Alloy 1x11, Hollow Spindle, Steel Narrow Wide 32T Chainring, 76mm BCD |
| Derailleur rear: | Shimano Deore 11-Speed |
| Fork: | RockShox Recon RL, 120mm Travel, Compression and Rebound Adjustment, Alloy Tapered Steerer, Solo Air Spring, 110x15mm Boost Spacing, Maxle Stealth, 51mm Offset |
| Fork brand: | RockShox |
| Fork material: | Alloy |
| Frame: | Series 2 Double Butted CrMo, 29" Wheels, Boost 141x9mm Open Dropout, 73mm Threaded BB, Plentiful Gear Mounts |
| Frame material: | Chromoly |
| Freewheel: | SunRace 11-Speed, 11-51T Cassette |
| Front travel: | 120mm |
| Gender: | Unisex |
| Grip: | Marin Bear Paw Locking |
| Grips: | Marin Bear Paw Locking |
| Groupset: | Shimano Deore |
| Groupset brand: | Shimano |
| Handlebar: | Marin Bedroll Bar, 50mm Rise, 780 Width, 10˚ Backsweep, 6˚ Upsweep |
| Handlebars: | Marin Bedroll Bar, 50mm Rise, 780 Width, 10˚ Backsweep, 6˚ Upsweep |
| Handlebar stem: | Marin 3D Forged Alloy, 35mm |
| Headset: | FSA Orbit ITA, Sealed Cartridge Bearings, 1 1/8" x 1 1/2” |
| Hubs: | FRONT: Forged Alloy, 110x15mm, Disc, 32H / REAR: Forged Alloy, 141x9mm, Disc, 32H |
| Mips rated: | false |
| Pedals: | Marin MTB Plastic |
| Puncture resistant: | false |
| Rim: | Alloy Double-Wall, Offset Spoke, 32mm ID, Tubeless Compatible |
| Rims: | Alloy Double-Wall, Offset Spoke, 32mm ID, Tubeless Compatible |
| Rotor front: | 180mm Rotor |
| Rotor rear: | 160mm Rotor |
| Saddle: | Marin Pine Mountain Trail |
| Season: | 2023 |
| Seatpost: | Marin Alloy, 30.9mm |
| Seat post: | Marin Alloy, 30.9mm |
| Shifters: | Shimano Deore 11-Speed |
| Speeds: | 1 x 11 |
| Spokes: | 14g Black Stainless Steel |
| Stem: | Marin 3D Forged Alloy, 35mm |
| Tubeless ready: | false |
| Tyre front: | Vee Tire Flow Snap, 29x2.6", Wire Bead |
| Tyre rear: | Vee Tire Flow Snap, 29x2.6", Wire Bead |
| Wheel size: | 29" |
| S | M | L | XL | |
|---|---|---|---|---|
| Stack | 629 | 633.4 | 638 | 642.6 |
| Reach | 420 | 450 | 475 | 505 |
| Headtube Angle | 66° | 66° | 66° | 66° |
| Headtube Length | 95 | 100 | 105 | 110 |
| Seattube Angle | 75° | 75° | 75° | 75° |
| Seattube Length | 381 | 431 | 482 | 520 |
| Toptube Effective | 588.5 | 620 | 646 | 677 |
| BB Height | 318 | 318 | 318 | 318 |
| BB Drop | 60 | 60 | 60 | 60 |
| Chainstay | 430 | 430 | 430 | 430 |
| Wheelbase | 1145 | 1177 | 1204 | 1236 |
| Standover Height | 697.55 | 742.45 | 786.98 | 818.91 |
| Fork Offset | 44 | 44 | 44 | 44 |
| Seatpost Diameter | 30.9 | 30.9 | 30.9 | 30.9 |
| Handlebar Width | 780 | 780 | 780 | 780 |
| Stem Length | 35 | 35 | 35 | 35 |
| Crank Length | 170 | 175 | 175 | 175 |
All lengths in millimeters
Marin Pine Mountain Bike Sizing Chart
Marin Bikes are Made For Fun. Since the first mountain bikes bearing the Marin name debuted in 1986, the brand has been dedicated to enriching the lives of riders by making fun, high caliber bicycles, which provide years of riding enjoyment. They operate their business based on hard work, fueled by passion, and fulfilled by the satisfaction of bringing the joy of cycling to riders across the world.
Click & Collect Available
• In-stock items usually ready in 4 hours* • Online Only items usually ready in 1-3 working days More info »
Courier Delivery Available
• $9.99 for orders $99 & under • Free for orders over $99 • Bulky shipping fees apply for bikes & bulky items based on item weight More info »
Please note, due to challenges in the product supply chain, bike specifications are subject to change without notice. Specifications listed below may not match exactly as shown in the photo.
