Marin El Roy Hardtail Mountain Bike Blue

Marin El Roy Hardtail Mountain Bike Blue

Brand: Marin

SKU: Select a size

Size: Select a size

MD LG

Not sure what sized bike is best?

Answer a few short questions and we'll make a recommendation on which size is best for you.

REQUEST A PRICE BEAT

Pick up Delivery

Your store:

No location set

No click & collect information available for this location.

Click & Collect:

In Store

Select a size to view stock availability at this store.

$9.90 Not available

Select a size to view stock availability at this location.

Chromoly Frame/ Marzocchi Alloy Fork

140mm Front Travel

29" Wheel Size

Hydraulic Disc Brake

Shimano Deore Groupset

1 x 12 Speed

Have a Question? Ask an expert on 0800 000 283

Product Details

Description

The El Roy is the ultimate aggressive steel hardtail that’ll get you to the top, and then really shine on the way down, with a spicy mix of progressive geometry and supple steel. This 29” wheel trail slayer was purpose built for silly fun days in the woods, no matter the conditions. Named in honour of the Marin teams favourite post-ride taqueria, the El Roy is wrapped up with a stout Series 3 double butted and formed CrMo frameset with investment cast dropouts, integrated drop-in headset, external brake and hose mounts, all full ED coated for longevity. Bosses on the underside of the top tube give the rider the option to mount tools and other accessories in a tidy fashion. Complementing the CrMo frame is the iconic Marzocchi Z1 fork (140mm), a 12-speed Shimano Deore drivetrain, X-Fusion Manic dropper post, 4-piston Shimano disc brakes and sticky Maxxis Assegai tires. Grab one of two frame sizes, Regular or Grande, and enjoy the delicious goodness that Marin cooked up.

Key Features

Series 3 Double Butted and Formed CrMo Frame
Marzocchi Z1, 140mm Travel Fork
Shimano Deore 12-Speed Drivetrain
Shimano BR-MT420, 4-Piston Hydraulic Disc Brakes
Maxxis Assegai 29 x 2.5" Tubeless Ready Tyres
X Fusion Manic Dropper Post
Available in two sizes; Regular and Grande

Specifications

Product Overview

Product

Marin El Roy Hardtail Mountain Bike Blue

Brand

Marin

Parent SKU

T1SN9GYW

Size SKUs

MD: MAHA2335874001
LG: MAHA2335874002

Year Model

2023

Product Features

Frame Material

Chromoly

Colour

Blue

Wheel Size

29"

Brake Type

Hydraulic Disc Brake

Gears

1 x 12

Fork Material

Alloy

Front Travel

140mm

Build

Frame

Series 3 Double Butted and Formed CrMo tubing, Integrated Drop-In Headset, External Rear Derailleur and Brake Housing, Internal Dropper Post Routing, 148x12mm Boost Rear Spacing, Post Mount Brake Mounts

Fork

Marzocchi Z1, 140mm Travel, EVOL Air Spring, GRIP Damper w/ Sweep Adjust, Kabolt 110 Axle, 44mm Offset

Handlebars

Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back

Headset

FSA Orbit 40 No.42 ACB

Grips

Marin Grizzly, Lock On

Stem

Marin 3D Forged Alloy, 35mm

Bottom Bracket

Mego EXO 73mm BSA

Saddle

Marin Speed Concept

Seat Post

X Fusion Manic, Regular = 150mm Travel, Grande = 170mm Travel

Wheels

Wheel Size

29"

Rims

Marin, Double Wall Alloy, 29mm Inner, Welded Joint, Disc Specific, 32H, Tubeless Compatible

Hubs

FRONT: Shimano HF-MT410B, 110x15mm, Disc / REAR: Shimano HB-MT410B, 148x12mm, Disc, Microspline Freehub Body

Spokes

14g Black Stainless Steel

Groupset

Crankset

FSA Comet, Modular 1x, 32T Direct Mount Chainring, MegaTooth Technology, Boost Spacing

Chain

KMC X-12 Silver and Black

Brakes

Shimano BR-MT420, 4-Piston Hydraulic Disc

Front Rotor

203mm Rotor

Rear Rotor

180mm Rotor

Shifters

Shimano Deore, M6100, 12-Speed

Rear Derailleur

Shimano Deore, 12-Speed, SGS

Cassette

12 Speed
