Marin Alpine Trail XR Enduro Bike Blue Black

Marin Alpine Trail XR Enduro Bike Blue Black

Brand: Marin

SKU: Select a size

Size: Select a size

SM MD LG XL

Not sure what sized bike is best?

Answer a few short questions and we'll make a recommendation on which size is best for you.

REQUEST A PRICE BEAT

Pick up Delivery

Your store:

No location set

No click & collect information available for this location.

Click & Collect:

In Store

Select a size to view stock availability at this store.

$9.90 Not available

Select a size to view stock availability at this location.

Alloy Frame/ Marzocchi Alloy Fork

160mm Front Travel / 150mm Rear

29" Wheel Size

Hydraulic Disc Brake

Shimano XT / SLX Groupset

1 x 12 Speed

Have a Question? Ask an expert on 0800 000 283

Product Details

Description

The Alpine Trail is a 29er full suspension bike built for the all day enduro rider that earns their downhill fun. Built for abuse and rowdy enduro style racing and riding, big wheels meet big fun. The XR model sits at the top of the aluminium frame line-up. The Series 4 aluminum frame, with detailed forgings, highly manipulated tubes, and full internal cable routing, gives the rider the highest-end alloy frame that Marin offers. The heart of the Alpine Trail’s MultiTrac suspension is the forged one-piece rocker link. The strength and stiffness of the rocker keeps the rear of the bike tracking straight, providing smooth suspension operation. The stiffness of the one-piece rocker link allows for a bridgeless seatstay design, offering zero compromises on stiffness while at the same time allowing for maximum tire clearance and short chainstays. The Alpine Trail has a slack head tube angle paired with a steep seat tube angle and long reach to provide the best modern trail bike experience.

Key Features

Series 4 6061 Aluminum Frame, 29” Wheels
Marin’s acclaimed MultiTrac Suspension Platform
Internal Dropper Post and Rear Derailleur Routing
Marzocchi Z1 Coil, 160mm Travel Fork
Marzocchi CR Coil, 150mm Travel Shock
Shimano SLX / XT 1 x 12 Speed Drivetrain
Shimano BR-MT420, 4-Piston Hydraulic Disc Brakes
Maxxis Assegai 29 x 2.5” Tubeless Ready Tyres

Specifications

Product Overview

Product

Marin Alpine Trail XR Enduro Bike Blue Black

Brand

Marin

Parent SKU

CO8RSBEQ

Size SKUs

SM: MADA2335967001
MD: MADA2335967002
LG: MADA2335967003
XL: MADA2335967004

Year Model

2023

Product Features

Frame Material

Alloy

Colour

Blue

Wheel Size

29"

Brake Type

Hydraulic Disc Brake

Gears

1 x 12

Fork Material

Alloy

Front Travel

160mm

Rear Travel

150mm

Build

Frame

Series 4 6061 Aluminum Frame, 29” Wheels, 150mm Travel MultiTrac Suspension Platform, Internal Dropper Post and Rear Derailleur Routing, Chainstay Mounted Post Mount Disc Brake, 148x12mm Boost Thru- Axle, 73mm Threaded BB w/ ISCG05 Tabs

Fork

Marzocchi Z1 Coil, 160mm Travel, Sweep Adjust Damper, Rebound Adjustment, Black Stanchions, 110x15 Kabolt, 44mm Offset

Shock

Marzocchi CR Coil, Compression and Rebound Adjustment, 205x65mm, Trunnion Upper Mount, M8x25mm Lower Mount, S/M 350lb Spring, L/XL 450lb Spring

Handlebars

Marin Trail, 35mm Clamp, 7000 Alloy Bar, 800mm Length, 20mm Rise, 5 Degree Up, 8 Degree Back

Headset

FSA No 57, Sealed Cartridge Bearings, 1 1/8" x 1 1/2”

Grips

Marin Single Clamp Locking

Stem

Marin CNC, 35mm Length, 35mm Bar Bore

Bottom Bracket

MEGAEVO BB, 73mm BSA Threaded

Saddle

Marin Speed Concept

Seat Post

TranzX, YSP23JL, 1x Remote, Size S 150mm Travel, Size M and L 170mm Travel, Size XL 200mm Travel, 30.9mm

Accessories

Downtube Protector

Wheels

Wheel Size

29"

Rims

Marin Aluminum Double Wall, 29mm Inner, Sleeved Joint, Disc Specific, Tubeless Compatible

Hubs

FRONT: Shimano HF-MT410B, 110x15mm, Centerlock / REAR: Shimano HB-MT510B, 148x12mm, Disc, Microspline Freehub Body

Spokes

14g Black Stainless Steel

Groupset

Crankset

FSA Gradient, Modular 1x, 32T Direct Mount Chainring, MegaTooth Technology, Mego EXO Spindle, Boost Spacing

Chain

KMC X-12 Silver and Black

Brakes

Shimano BR-MT420, 4-Piston Hydraulic Disc

Front Rotor

203mm Rotor

Rear Rotor

180mm Rotor

Shifters

REAR: Shimano SLX 12-Speed, I-Spec EV

Rear Derailleur

Shimano XT 12-Speed, SGS

Cassette

12 Speed

Find Your Size

Step 1: Measure your height

Take off your shoes
Stand with your back straight against a wall
Balance a book on your head to mark your height on the wall
Measure your height by the distance from the floor to the mark

Your height:

Find Your Size

Step 2: Adjust your inseam

Based on your height, we’ve calculated a starting point.
You can measure your inseam by tucking a book between your legs so there is pressure but it isn’t uncomfortable.
Inseam typically falls with 5cm of the average.

Your inseam:

Find Your Size

Your results

For the Marin Alpine Trail XR Enduro Bike Blue Black we suggest the following size.

More comfort More speed

Height: --

Inseam: --

Adjusted Height: --

Find Your Size

We have saved your measurements.

Recommended sizes will now be highlighted on the page.

PERFECT RIDE GUARANTEE

If you don't love it, you can swap it, up to 30 days from purchase!* Learn more »

FREE BIKE BUILD

We'll build your bike for free when you click and collect at any 99 Bikes store.

FIRST FREE TUNE-UP

Every bike comes with a complimentary free tune-up and safety check. Learn more »

Not sure what sized bike is best?

Answer a few short questions and we'll make a recommendation on which size is best for you.

Your selected size: -

Legend

Available size

Current size

Unavailable size

Suggested sizing

Marin Alpine Trail XR Enduro Bike Blue Black geometry diagram

Legend

ST Seat Tube
STA Seat Tube Angle
R Reach
TT Top Tube
BD Bottom Bracket Drop
S Stack
CS Chain Stay Length
HT Head Tube
WB Wheel Base
HTA Head Tube Angle
FL Fork Length

Wheel Size

29"

Stack

Reach

Top Tube Length

Seat Tube Length

Seat Tube Angle

Fork Length

Head Tube Length

Head Tube Angle

Handlebar Height

Bottom Bracket Drop

Chainstay Length

Wheelbase

Standover Height

Minimum Seat Height

Maximum Seat Height
