40% Off Full Price

Marin Alpine Trail E1 Electric Enduro Bike Green/Black

Marin Alpine Trail E1 Electric Enduro Bike Green/Black

Brand: Marin

SKU: Select a size

Size: Select a size

SM MD LG XL

Not sure what sized bike is best?

Answer a few short questions and we'll make a recommendation on which size is best for you.

REQUEST A PRICE BEAT

Pick up Delivery

Your store:

No location set

No click & collect information available for this location.

Click & Collect:

In Store

Select a size to view stock availability at this store.

$9.90 Not available

Select a size to view stock availability at this location.

Steep Hills & Heavy Loads / 85 Nm Torque

Up to 73 km Range

Shimano STePS EP6 Motor

Alloy Frame/ X-Fusion Alloy Fork

160mm Front Travel / 150mm Rear

630Wh Battery

Have a Question? Ask an expert on 0800 000 283

Product Details

Description

Marin took all the greatness of their longest travel, most aggressive enduro platform to make their most capable eMTB to date. With the same acclaimed MultiTrac chassis and progressive geometry as the conventional Alpine Trail models, but with an electric boost to take you into bigger adventures than ever before. The Alpine Trail E1 sits in the middle of the lineup, packing performance and value in equal measure. The 630Wh battery is integrated into a Series 4 aluminium frame, with detailed forgings, highly manipulated tubes, and full internal cable routing. Add in a new Shimano EP6 motor with a whopping 85Nm of torque for all-day all-mountain riding. The multitrack suspension platform offers up a X-Fusion Trace 36RC 160mm fork paired with a RockShox Super Deluxe Coil R shock. Lastly, a reliable Shimano 11-speed Deore drivetrain, burly Shimano 4-piston hydraulic disc brakes, TranzX dropper post and a mullet wheel setup with 29” up front and 27.5”+ in the rear round off this epic bui

Key Features

New Series 4 Alloy Frame, Marin Multitrac suspension system
Shimano STEPS EP6 Drive Unit, 250W, 85Nm
Shimano BT-8036, Internal 630Wh Battery
X-Fusion Trace 36 RC, 160mm Travel Fork
RockShox Super Deluxe Coil R Shock
Shimano Deore, 1x11-Speed Drivetrain
Shimano MT420, 4-Piston Hydraulic Disc Brakes

Specifications

Product Overview

Product

Marin Alpine Trail E1 Electric Enduro Bike Green/Black

Brand

Marin

Parent SKU

FBVN5DTN

Size SKUs

SM: MAEB2335965001
MD: MAEB2335965002
LG: MAEB2335965003
XL: MAEB2335965004

Product Features

Frame Material

Alloy

Colour

Green

Wheel Size

29" / 27.5" (Mullet Bike)

Brake Type

Hydraulic Disc Brake

Gears

1 x 11

Fork Material

Alloy

Front Travel

160mm

Rear Travel

150mm

Motor and Battery System

Drive Type

Mid Drive

Motor Brand

Shimano

Torque (Nm)

Motor Climbing Ability

Steep Hills & Heavy Loads

Battery Size (Watt-Hours)

630

Battery

Shimano BT-8036, Internal 630Wh / Shimano Battery Charger EC-E6002

Max. Range (KMs)

Display

SC-E600 Display

Build

Frame

Series 4 Alloy Frame, 150mm Multitrac Suspension, Integrated Battery/Charging Port, 148mm Rear Thru-Axle, Built-in Rear Speed Sensor

Fork

X-Fusion Trace 36 RC, 160mm Travel, 29”, 110x15mm Bolt-On Axle, 44mm Offset

Shock

RockShox Super Deluxe Coil R, Rebound Adjustment, 205x65mm, 25mmxM8 Lower Hardware, S/M Spring Rate = 300lb, L/XL Spring Rate = 400lb

Handlebars

Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back

Headset

FSA No 57E, Sealed Cartridge Bearings, 1 1/8" x 1 1/2”

Grips

Marin Grizzly, Lock On

Stem

Marin 3D Forged Alloy, 35mm

Pedals

Marin MTB Plastic

Saddle

Marin E-MTB

Seat Post

TranzX, YSP23JL, 1x Remote, Size S 150mm Travel, Size M and L 170mm Travel, Size XL 200mm Travel, 30.9mm

Wheels

Wheel Size

29" / 27.5" (Mullet Bike)

Rims

Front: Marin Aluminum Double Wall, 29" Diameter, 32mm Inner Rim Width, Pinned Joint, Disc Specific, Tubeless Compatible; Rear: Marin Aluminum Double Wall, 27.5" Diameter, 38mm Inner Rim Width, Pinned Joint, Disc Specific, Tubeless Compatible

Hubs

FRONT: Shimano MT-410B, 110x15mm, centerlock Disc, 32H / REAR: Shimano HB-MT400B, 148x12mm, Centerlock, Standard Freehub Body

Spokes

14g Black Stainless Steel

Groupset

Crankset

Shimano EM600, 160mm Length

Chain

KMC X-10E, Silver

Brakes

Shimano MT420, 4-Piston Hydraulic Disc, Metallic Pads, 203mm Rotor (Rear offers speed sensor)

Shifters

Shimano Deore, 11-Speed, I Spec EV

Rear Derailleur

Shimano Deore, Direct Attachment, 11-Speed, SGS

Cassette

11 Speed

Find Your Size

Step 1: Measure your height

Take off your shoes
Stand with your back straight against a wall
Balance a book on your head to mark your height on the wall
Measure your height by the distance from the floor to the mark

Your height:

Find Your Size

Step 2: Adjust your inseam

Based on your height, we’ve calculated a starting point.
You can measure your inseam by tucking a book between your legs so there is pressure but it isn’t uncomfortable.
Inseam typically falls with 5cm of the average.

Your inseam:

Find Your Size

Your results

For the Marin Alpine Trail E1 Electric Enduro Bike Green/Black we suggest the following size.

More comfort More speed

Height: --

Inseam: --

Adjusted Height: --

Find Your Size

We have saved your measurements.

Recommended sizes will now be highlighted on the page.

PERFECT RIDE GUARANTEE

If you don't love it, you can swap it, up to 30 days from purchase!* Learn more »

FREE BIKE BUILD

We'll build your bike for free when you click and collect at any 99 Bikes store.

FIRST FREE TUNE-UP

Every bike comes with a complimentary free tune-up and safety check. Learn more »

Not sure what sized bike is best?

Answer a few short questions and we'll make a recommendation on which size is best for you.

Your selected size: -

Legend

Available size

Current size

Unavailable size

Suggested sizing

Marin Alpine Trail E1 Electric Enduro Bike Green/Black geometry diagram

Legend

ST Seat Tube
STA Seat Tube Angle
R Reach
TT Top Tube
BD Bottom Bracket Drop
S Stack
CS Chain Stay Length
HT Head Tube
WB Wheel Base
HTA Head Tube Angle
FL Fork Length

Wheel Size

29" / 27.5" (Mullet Bike)

Stack

Reach

Top Tube Length

Seat Tube Length

Seat Tube Angle

Fork Length

Head Tube Length

Head Tube Angle

Handlebar Height

Bottom Bracket Drop

Chainstay Length

Wheelbase

Standover Height

Minimum Seat Height

Maximum Seat Height
