- Lightweight 6061 racelite aluminium frame
- Suntour XCT-JR 50mm custom tuned fork
- Shimano 1x8 speed drivetrain
- Tektro hydraulic disc brakes
- 24” wheels with fast rolling tyres
- Kid specific finishing kit
- Kickstand included
- Integrated mounts for mudguard and rear carrier
Bottom bracket: | Bearing cartridge |
---|---|
Brakes: | Tektro M275, two pistons |
Chain: | Sunrace M84 |
Crankset: | MERIDA EXPERT JR, 28T 140 mm |
Derailleur rear: | Shimano RD-M310 |
Fork: | Suntour XCT-JR, Custom coil, 50mm suspension travel |
Frame: | MATTS J. 24, Aluminium, 24", 135x9/100x9, BSA Bottom Bracket |
Freewheel: | Sunrace CSM558, 11-34 teeth, 8 speed Cassette |
Grip: | MERIDA EXPERT JR |
Handlebar: | MERIDA EXPERT JR, Aluminium, 620mm width, 20mm rise |
Handlebar stem: | MERIDA EXPERT CC, Aluminium, 31.8mm diameter, -5° Rise, 60 mm |
Headset: | VP Z104AE |
Hubs: | FRONT: Joytech D761DSE, 100x9mm width front hub, 24 spoke holes / REAR: Joytech D762TSE, 135x9mm width rear hub, 24 spoke holes |
Pedals: | Marwi SP-202 |
Rim: | MERIDA JR 24+, Aluminium |
Rotor front: | Tektro, 160mm |
Rotor rear: | Tektro, 140mm |
Saddle: | MERIDA EXPERT JR |
Season: | 2022 |
Seat clamp: | MERIDA COMP QR |
Seat post: | MERIDA COMP CC, MAT aluminium, 30.9mm, 0° Setback |
Tyre front: | Kenda Small Block 8, 24x1.95", fold |
Tyre rear: | Kenda Small Block 8, 24x1.95", fold |
Weight: | 10.4kg |
Wheel size: | 24" |
Frame Size | 11.5" |
Tyre Sizes | 24" |
ST seat tube [mm] | 275 |
TT top tube [mm] | 500 |
CS chain stay length [mm] | 410 |
HTA head tube angle [°] | 68 |
STA seat tube angle [°] | 72 |
BD bottom bracked drop [mm] | 30 |
HT head tube [mm] | 120 |
FL fork length [mm] | 415 |
R reach [mm] | 335 |
S stack [mm] | 509 |
WB wheel base [mm] | 986 |
SH stand over height [mm] | 560 |
Kids Bike Sizing Chart
Merida Bikes Warranties
Lifetime warranty on all frames
Lifetime warranty on all frames for the entire ownership of the original purchaser. This covers manufacturing and material defects. No exclusions for racing. Rider and equipment weight limit: 120kg for standard bikes; 140kg for e-Bikes. Proof of purchase must be presented. (frames from model year 2015 onwards). *Conditions apply. *The lifespan of a bike is up to ten years.
Forks: Carbon and aluminium rigid forks are guaranteed for 5 years from the date of purchase
Suspension: Rear suspension components are guaranteed for 2 years from the date of purchase
All other MERIDA branded components, including paint and finish, are guaranteed for 1 year from the date of purchase.
The Merida Warranty Excludes:
Componentry which isn’t Merida branded (see below)
Normal wear and tear
Damage caused by accidents, neglect or abuse
Improper assembly
Improper follow-up maintenance; all bikes must be serviced by an authorised MERIDA dealer within 6 months of purchase. Suspension systems must be serviced annually by an authorised dealer
Modification or alteration of the frame or original components
Branded Components
Issues relating to branded original components, such as Shimano or SRAM are the responsibility of the appropriate component manufacturer’s warranty and subject to their terms and conditions.
In the case of branded components failing, please contact your local MERIDA stockist who will liaise with the relevant distributor on your behalf.
If the cause of the fault isn’t initially clear based on the information and photos your MERIDA stockists provides, the defective product may need to be returned to MERIDA Bicycles Ltd for closer inspection.
Merida is an international bike brand with its headquarters in Taiwan, the R&D department is based near Stuttgart in Germany. To be based in Germany has historical reasons for MERIDA but the precise location was chosen specifically because the region around Stuttgart is one of the hot spots of the automotive and machine building industry which Germany is famous for and attracts a hugely skilled design and engineer labor force.
The Merida team are more than just highly trained and experienced bicycle creators – they simply love everything ‘bike’. Most of their R&D staff are daily bike commuters while others are serious mountain bikers, who regularly compete in Marathon, Enduro and Downhill competitions, or licensed road racers and even ambitious Ironman triathletes. Get the behind the scenes view of the Merida R&D centre and meet some of their key members of staff in the below video.
