Cube Stereo 170 Pro Enduro Bike 29" Wheels Anodized

Cube Stereo 170 Pro Enduro Bike 29" Wheels Anodized

Brand: Cube

SKU: Select a size

Size: Select a size

MD LG

Not sure what sized bike is best?

Answer a few short questions and we'll make a recommendation on which size is best for you.

REQUEST A PRICE BEAT

Pick up Delivery

Your store:

No location set

No click & collect information available for this location.

Click & Collect:

In Store

Select a size to view stock availability at this store.

$9.90 Not available

Select a size to view stock availability at this location.

Alloy Frame/ Fox Alloy Fork

170mm Front Travel / 160mm Rear

29" Wheel Size

Hydraulic Disc Brake

SRAM GX Eagle Groupset

1 x 12 Speed

Have a Question? Ask an expert on 0800 000 283

Product Details

Description

Big wheels, big travel, big fun. The Stereo ONE170 redefines what a big-travel, big-wheeled bike can do. The advanced hydroformed alloy frame is designed around Cube’s proven four-bar suspension system and Agile Trail Geometry, for superb suspension performance and dependable handling in a huge range of trail conditions. New for 2022, Cube reduced the seat tube length to improve standover and increased the reach on larger frame sizes. The shock setup is more progressive and there's an AngleSet so you can tweak the geometry to suit your own preference. The Fox 38 Float fork and Float X2 Performance shock work in perfect symmetry with the revised geometry and kinematics, while the SRAM GX Eagle 1x12 transmission makes light work of any terrain. Magura's powerful MT5 hydraulic disc brakes are optimized for gravity riding, perfect for brake control when bombing techy descents. The Newmen Evolution wheels are designed to be punished and engineered to withstand the toughest enduro terrain.

Key Features

HPA Advanced Hydroform Alloy Frame
Agile Trail Geometry, Cub Four-Bar Suspension System
Fox 38 Float Performance GRIP 170mm Fork
Fox Float X2 Shock, Low-Speed Rebound & Compression
SRAM GX Eagle 1 x 12 Speed Drivetrain
Magura MT5 Hydraulic Disc Brakes
Durable Newmen Evolution SL 29” wheels

Specifications

Product Overview

Product

Cube Stereo 170 Pro Enduro Bike 29" Wheels Anodized

Brand

Cube

Parent SKU

FSMFOJEK

Size SKUs

MD: 556100-000M
LG: 556100-000L

Matrix Barcodes

MD: 4054571354822
LG: 4054571354839

Year Model

2022

Product Features

Frame Material

Alloy

Colour

Black

Wheel Size

29"

Brake Type

Hydraulic Disc Brake

Gears

1 x 12

Fork Material

Alloy

Front Travel

170mm

Rear Travel

160mm

Weight

15.5kg / Max System Weight (rider + luggage carriers etc.): 115kg

Build

Frame

HPA Advanced Hydroform, ATG, ETC 4-Link, Air/Coil Mount Flip-Chip, ISCG Mount, AXH

Fork

Fox 38 Float Performance GRIP, 3-Position w/Micro Adjust, Tapered, 15x110mm, 170mm

Shock

Fox Float X2, 230x65mm, Low Speed Rebound & Compression w/ 2-Position Lever / Hardware: Top: 40x8mm, Bottom: 20x8mm

Handlebars

Race Face Chester 35, 780mm

Headset

ACROS Integrated, Top 1 1/8", Bottom 1 1/2", Fiber Inserts for 0.6° Angle Adjustment

Grips

Natural Fit MTB Stiffler Lock On, Soft Compound

Stem

Race Face Aeffect R 35

Saddle

Natural Fit Venec Lite

Seat Post

CUBE Dropper Post, Lever, Internal Cable Routing, 31.6mm, 150mm

Seat Clamp

CUBE Screwlock, 34.9mm

Wheels

Wheel Size

29"

Rims

Newmen Evolution SL A.30, 28/28 Spokes, 15x110mm/12x148mm, Tubeless Ready

Groupset

Crankset

Sram GX Eagle™ Boost DUB, 30T, 170mm

Chain

Sram SX Eagle™

Brakes

Magura MT5, Hydr. Disc Brake (203/180)

Front Rotor

203mm

Rear Rotor

180mm

Shifters

Sram NX Eagle™ Trigger

Rear Derailleur

Sram GX Eagle™, 12-Speed

Cassette

12 Speed

Find Your Size

Step 1: Measure your height

Take off your shoes
Stand with your back straight against a wall
Balance a book on your head to mark your height on the wall
Measure your height by the distance from the floor to the mark

Your height:

Find Your Size

Step 2: Adjust your inseam

Based on your height, we’ve calculated a starting point.
You can measure your inseam by tucking a book between your legs so there is pressure but it isn’t uncomfortable.
Inseam typically falls with 5cm of the average.

Your inseam:

Find Your Size

Your results

For the Cube Stereo 170 Pro Enduro Bike 29" Wheels Anodized we suggest the following size.

More comfort More speed

Height: --

Inseam: --

Adjusted Height: --

Find Your Size

We have saved your measurements.

Recommended sizes will now be highlighted on the page.

PERFECT RIDE GUARANTEE

If you don't love it, you can swap it, up to 30 days from purchase!* Learn more »

FREE BIKE BUILD

We'll build your bike for free when you click and collect at any 99 Bikes store.

FIRST FREE TUNE-UP

Every bike comes with a complimentary free tune-up and safety check. Learn more »

Not sure what sized bike is best?

Answer a few short questions and we'll make a recommendation on which size is best for you.

Your selected size: -

Legend

Available size

Current size

Unavailable size

Suggested sizing

Cube Stereo 170 Pro Enduro Bike 29" Wheels Anodized geometry diagram

Legend

ST Seat Tube
STA Seat Tube Angle
R Reach
TT Top Tube
BD Bottom Bracket Drop
S Stack
CS Chain Stay Length
HT Head Tube
WB Wheel Base
HTA Head Tube Angle
FL Fork Length

Wheel Size

29"

Stack

629

627

Reach

464

444

Top Tube Length

605

585

Seat Tube Length

420

Seat Tube Angle

76.5

Fork Length

Head Tube Length

105

103

Head Tube Angle

105.0

103.0

Handlebar Height

Bottom Bracket Drop

Chainstay Length

Wheelbase

Standover Height

Minimum Seat Height

Maximum Seat Height
