- C:68X Carbon Frame, Monocoque Advanced Twin Mold Tech
- Agile Ride Geometry, internal cable routing, dropper ready
- RockShox SID Ultimate 100mm Fork
- SRAM XX1 Eagle 1 x 12 Speed Drivetrain
- Magura MT8 SL Hydraulic Disk Brakes
- Newmen Evolution SL Tubeless-ready Wheelset
Axles: | 15x110mm / 12x148mm |
---|---|
Brakes: | Magura MT8 SL, Hydr. Disc Brake (180/160) |
Chain: | Sram PC-X01 Eagle™ |
Crankset: | Sram XX1 Eagle™ DUB, 34T, 175mm (S: 170mm) |
Derailleur rear: | Sram XX1 Eagle™, 12-Speed |
Fork: | RockShox SID Ultimate, Fast Black, Tapered, 15x110mm, 100mm, OneLoc |
Frame: | C:68X Monocoque Advanced Twin Mold Technology, ARG2, Tapered Headtube, PressFit BB, Boost 12x148mm, Integrated Cable Routing, Dropper Post ready |
Freewheel: | Sram XG-1295, 10-52T |
Grip: | Cube Race SL Grip 29.5mm, 1-Clamp |
Handlebar: | Newmen Advanced 318.0, Carbon, 740mm |
Handlebar stem: | Newmen Evolution SL 318.4, 31.8mm |
Headset: | Acros AzX/AiX, block lock, Top: semi 1 1/8", Bottom: 1 1/2" |
Rim: | Newmen Evolution SL X.A.25, 28/28 Spokes, 15x110mm / 12x148mm, Tubeless Ready |
Rotor front: | 180mm |
Rotor rear: | 160mm |
Saddle: | Natural Fit Nuance SL |
Season: | 2021 |
Seat clamp: | CUBE Superlight, 30.8mm |
Seat post: | Newmen Advanced Custom, Carbon, 27.2mm |
Spokes: | 28/28 Spokes |
Tyre front: | Schwalbe Racing Ray, Super Race, Addix Speedgrip, Kevlar, 2.25 |
Tyre rear: | Schwalbe Racing Ralph, Super Race, Addix Speed, Kevlar, 2.25 |
Weight: | 8.9 kg / Max system weight (rider & accessories): 115kg |
Wheel size: | 29" |
16" / 29 / S | 18" / 29 / M | 20" / 29 / L | 22" / 29 / XL | |
SEAT TUBE | 370 | 420 | 470 | 515 |
TOP TUBE HORIZONTAL | 575 | 600 | 625 | 650 |
SEAT TUBE ANGLE | 73.8 | 73.8 | 73.8 | 73.8 |
HEAD TUBE ANGLE | 69 | 69 | 69 | 69 |
CHAIN STAYS | 424 | 424 | 424 | 424 |
HEAD TUBE | 90 | 98 | 111 | 129 |
WHEELSBASE | 1077.1 | 1102.6 | 1128.4 | 1154.5 |
BB-HEIGHT TO HUB | 63 | 63 | 63 | 63 |
STANDOVER HEIGHT | 739 | 750 | 781 | 804 |
REACH | 401.7 | 424.4 | 445.6 | 465.5 |
STACK | 602.4 | 609.9 | 622 | 638.9 |
STEM LENGTH | 70 | 80 | 80 | 90 |
ANGLE STEM | 6 | 6 | 6 | 6 |
HANDLEBAR WIDTH | 740 | 740 | 740 | 740 |
LENGTH SEAT POST | 400 | 400 | 400 | 400 |
DIAMETER SEATPOST | 27.2 | 27.2 | 27.2 | 27.2 |
CRANK LENGTH | 170 | 170 | 175 | 175 |
Cube Bike Sizing Chart
