$540 Off Full Price

Norco Range C3 Enduro Racing Bike Red/Silver

Norco Range C3 Enduro Racing Bike Red/Silver

Brand: Norco

SKU: 8P5ZVVP0

Size: SM

REQUEST A PRICE BEAT

Pick up Delivery

Your store:

No location set

No click & collect information available for this location.

Click & Collect:

In Store

Select a size to view stock availability at this store.

$9.90 Not available

Select a size to view stock availability at this location.

Alloy Frame/ RockShox Alloy Fork

170mm Front Travel / 160mm Rear

29" Wheel Size

Hydraulic Disc Brake

Shimano Deore Groupset

1 x 12 Speed

Have a Question? Ask an expert on 0800 000 283

Product Details

Description

The Range is designed from the ground-up for the world’s fastest, roughest Enduro courses, and to meet the needs of Big Mountain riders who crave speed on technical trails in the backwoods. Norco applied their legendary Ride Aligned™ Design System in a whole new way, not only does each frame size benefit from different rear-center lengths and seat tube angles, but the ideal head tube angle is different for every frame size. Mass is kept low in the frame due to the suspension layout and shock position, for exceptional tracking in the rough, a balanced level of suspension support front and rear to maintain stable body position in varied terrain, and efficient pedaling on climbs. Norco’s extensive testing consistently showed that 29” wheels roll faster in the conditions riders face on most Enduro racecourses. Riders can stay centered on the bike, even in the steepest, nastiest terrain, and the rearward axle path avoids rider contact under heavy compression.

Key Features

Engineered for Enduro racing, and perfect for backwoods shenanigans.
High Virtual Pivot suspension for precision and reduced fatigue.
Size specific geometry makes everyone faster.
Save energy on the way up so there’s more later in the day.
High speed stability that responds instantly to rider input.
Perfect fit, dialed handling and personalized setup in minutes.

Specifications

Product Overview

Product

Norco Range C3 Enduro Racing Bike Red/Silver

Brand

Norco

Parent SKU

D125IXUK

Year Model

2023

Product Features

Frame Material

Alloy

Colour

Red

Wheel Size

29"

Brake Type

Hydraulic Disc Brake

Gears

1 x 12

Fork Material

Alloy

Front Travel

170mm

Rear Travel

160mm

Build

Frame

Full Carbon, 170mm Travel, Ride Aligned

Fork

RockShox ZEB, Charger R, 170mm Travel, 44mm offset

Shock

FOX DHX2 Factory Coil, HSC/LSC, HSR/LSR,Custom Tune, 205x65mm Trunnion

Handlebars

6061 Aluminum, 800mm, 25mm Rise

Headset

FSA #57 E Internal Sealed Bearing

Grips

DMR DeathGrip Soft, Thin (S, M), Thick (L,XL)

Stem

e*thirteen Base, 40mm Length, 35mm Clamp

Bottom Bracket

SRAM DUB PF92

Saddle

WTB Volt 250 Sport

Seat Post

TranzX YSP-105 Adjustable Dropper, 34.9mm,150mm (S), 170mm (M), 200mm (L, XL)

Wheels

Wheel Size

29"

Rims

Stan’s Flow D, 32H, 29”

Hubs

FRONT: Shimano HB-MT410, 15x110mm Boost, Center Lock / REAR: Shimano FH-MT510, 12x148mm Boost, Micro Spline,Center Lock

Spokes

Stainless - Black

Groupset

Crankset

Shimano Deore FC-MT510-1, 32T, 170mm

Chain

Shimano Deore CN-M6100, Chain Guide: Custom MRP SXg

Brakes

Shimano BR-MT520, 4 piston, Metallic Pads

Front Rotor

Shimano RT-64, 203mm

Rear Rotor

Shimano RT-64, 203mm

Shifters

Shimano SLX SL-M7100-R

Rear Derailleur

Shimano SLX RD-M7100

Cassette

12 Speed

Find Your Size

Step 1: Measure your height

Take off your shoes
Stand with your back straight against a wall
Balance a book on your head to mark your height on the wall
Measure your height by the distance from the floor to the mark

Your height:

Find Your Size

Step 2: Adjust your inseam

Based on your height, we’ve calculated a starting point.
You can measure your inseam by tucking a book between your legs so there is pressure but it isn’t uncomfortable.
Inseam typically falls with 5cm of the average.

Your inseam:

Find Your Size

Your results

For the Norco Range C3 Enduro Racing Bike Red/Silver we suggest the following size.

More comfort More speed

Height: --

Inseam: --

Adjusted Height: --

Find Your Size

We have saved your measurements.

Recommended sizes will now be highlighted on the page.

PERFECT RIDE GUARANTEE

If you don't love it, you can swap it, up to 30 days from purchase!* Learn more »

FREE BIKE BUILD

We'll build your bike for free when you click and collect at any 99 Bikes store.

FIRST FREE TUNE-UP

Every bike comes with a complimentary free tune-up and safety check. Learn more »

Your selected size: SM

Legend

Available size

Current size

Unavailable size

Suggested sizing

Norco Range C3 Enduro Racing Bike Red/Silver geometry diagram

Legend

ST Seat Tube
STA Seat Tube Angle
R Reach
TT Top Tube
BD Bottom Bracket Drop
S Stack
CS Chain Stay Length
HT Head Tube
WB Wheel Base
HTA Head Tube Angle
FL Fork Length

Wheel Size

29"

Stack

Reach

Top Tube Length

Seat Tube Length

Seat Tube Angle

Fork Length

Head Tube Length

Head Tube Angle

Handlebar Height

Bottom Bracket Drop

Chainstay Length

Wheelbase

Standover Height

Minimum Seat Height

Maximum Seat Height
