Merida Big Nine 60 X2 Hardtail Mountain Bike Matt Bronze/Black

Merida Big Nine 60 X2 Hardtail Mountain Bike Matt Bronze/Black

Brand: Merida

SKU: Select a size

Size: Select a size

LG XL XXL

Not sure what sized bike is best?

Answer a few short questions and we'll make a recommendation on which size is best for you.

REQUEST A PRICE BEAT

Pick up Delivery

Your store:

No location set

No click & collect information available for this location.

Click & Collect:

In Store

Select a size to view stock availability at this store.

$9.90 Not available

Select a size to view stock availability at this location.

Alloy Frame/ RockShox Alloy Fork

100mm Front Travel

29" Wheel Size

Hydraulic Disc Brake

Shimano Altus Groupset

2 x 9 Speed

Have a Question? Ask an expert on 0800 000 283

Product Details

Description

The Big Nine 60 X2 is a build designed for the rider ready to enter the world of single-track mountain biking and who needs a versatile bike with modern geometry and reliable, quality components. Packed with class leading features, like smooth welding for a premium finished look, or internal cable routing, which offers a sleek aesthetic as well as a rattle free ride. Merida even designed a clever downtube exit for easy servicing. The Racelite 61 aluminium frame reduces weight and maximizes strength, while the speed focused geometry maximizes pedal power without compromising on comfort. Rolling on 29" wheels, a 100mm travel Rock Shox Judy TK front fork will iron out any bumps while the Shimano 2x9 speed drivetrain and Hydraulic disc brakes provide reliable quality and optimal stopping performance. Integrated mounts for fenders, rear carrier rack and a kickstand means this build is also customizable making it an excellent everyday ride that can still thrash a trail on the weekends.

Key Features

Lightweight Racelite 61 aluminium frame
100mm travel Rock Shox Judy TK fork
Shimano 2x9 speed drivetrain
Hydraulic disc brakes for optimal stopping
Customizable with integrated mounts

Specifications

Product Overview

Product

Merida Big Nine 60 X2 Hardtail Mountain Bike Matt Bronze/Black

Brand

Merida

Parent SKU

TBPRDM93

Size SKUs

LG: MEHA2195979
XL: MEHA2195980
XXL: MEHA2195991

Matrix Barcodes

LG: 4710949808266
XL: 4710949808297
XXL: 4710949808303

Year Model

2021

Product Features

Frame Material

Alloy

Colour

Brown

Wheel Size

29"

Brake Type

Hydraulic Disc Brake

Gears

2 x 9

Fork Material

Alloy

Front Travel

100mm

Build

Frame

BIG.SEVEN TFS III material: aluminium 27.5x2.25" max. wheelsize 135x9mm axle standard BSA bottom bracket standard

Fork

Rock Shox Judy TK Coil 100mm suspension travel Lockout 42mm fork offset 27.5x2.25" max. wheelsize

Handlebars

MERIDA CC material: aluminium 690mm width 15mm rise

Headset

MERIDA M2345

Stem

MERIDA CC material: aluminium 31.8mm diameter 6° stem angle 70 mm-XS/S, 80 mm-M, 90 mm-L

Bottom Bracket

BSA bottom bracket standard

Saddle

MERIDA Sport comfort

Seat Post

MERIDA CC material: aluminium 30.9mm diameter 15mm setback

Wheels

Wheel Size

29"

Rims

MERIDA CC 17mm inner width material: aluminium

Hubs

Shimano TX505 100x9mm width front hub 32 spoke holes Centerlock

Tyres

MERIDA K1080 29x2.2" wire

Spokes

Black steel

Groupset

Crankset

170 mm-XS/S, 175 mm-M/L

Chain

KMC M99

Brakes

Shimano ST-EF505 BR-MT200 brake caliper

Shifters

Shimano ST-EF505

Rear Derailleur

Shimano RD-M370

Cassette

9 Speed

Find Your Size

Step 1: Measure your height

Take off your shoes
Stand with your back straight against a wall
Balance a book on your head to mark your height on the wall
Measure your height by the distance from the floor to the mark

Your height:

Find Your Size

Step 2: Adjust your inseam

Based on your height, we’ve calculated a starting point.
You can measure your inseam by tucking a book between your legs so there is pressure but it isn’t uncomfortable.
Inseam typically falls with 5cm of the average.

Your inseam:

Find Your Size

Your results

For the Merida Big Nine 60 X2 Hardtail Mountain Bike Matt Bronze/Black we suggest the following size.

More comfort More speed

XXL

Height: --

Inseam: --

Adjusted Height: --

Find Your Size

We have saved your measurements.

Recommended sizes will now be highlighted on the page.

PERFECT RIDE GUARANTEE

If you don't love it, you can swap it, up to 30 days from purchase!* Learn more »

FREE BIKE BUILD

We'll build your bike for free when you click and collect at any 99 Bikes store.

FIRST FREE TUNE-UP

Every bike comes with a complimentary free tune-up and safety check. Learn more »

XXL

Not sure what sized bike is best?

Answer a few short questions and we'll make a recommendation on which size is best for you.

Your selected size: -

Legend

Available size

Current size

Unavailable size

Suggested sizing

Merida Big Nine 60 X2 Hardtail Mountain Bike Matt Bronze/Black geometry diagram

Legend

ST Seat Tube
STA Seat Tube Angle
R Reach
TT Top Tube
BD Bottom Bracket Drop
S Stack
CS Chain Stay Length
HT Head Tube
WB Wheel Base
HTA Head Tube Angle
FL Fork Length

Wheel Size

29"

Stack

642

656

670

Reach

414

429

445

Top Tube Length

610

630

650

Seat Tube Length

470

510

560

Seat Tube Angle

73.0

Fork Length

506

Head Tube Length

130

145

160

Head Tube Angle

130.0

145.0

160.0

Handlebar Height

Bottom Bracket Drop

Chainstay Length

Wheelbase

Standover Height

763

800

843

Minimum Seat Height

Maximum Seat Height
